ASTM A234 WPB Sch40 90-Degree Short-Radius Carbon Steel Elbow Enquiry

• warranty

  1 year
  customized support

  OEM, ODM
• model number

  elbow 7109
  Technic

  Casting
• Connectivity

  Male/Female
  shape

  Equal/Reducing
• head code

  Hexagon/Round
  Overall Length

  4 in
• Height

  3
  Surface Treatment

  Painting
• Pressure

  Low Pressure
  System of Measurement

  inch
• Mounting hole diameter

  0.25 in
  Pipe Features

  Flexible, Corrosion-resistant, Chemical Resistant, Uv Resistant, No additional Features, underground rated
• Pipe Class

  125
  Application

  Agricultural Irrigation, Automotive Repair, Heating Systems, Power Industry, Construction Engineering, Shipbuilding, petrochemical industry
• Thread Types

  NPT

This pipe elbow page supports an ASTM A234 WPB carbon steel enquiry for a 90-degree short-radius turn with a Schedule 40 wall requirement. Define the available installation space and the actual geometry needed for the piping layout. The selected fitting also requires confirmed end dimensions, material scope and connection details.

Check the compact turn against the layout

Provide the required centerline radius and center-to-end dimensions on a drawing, along with the permitted installation envelope. A short-radius description needs a dimensional basis before it can establish clearance around equipment or adjacent pipework. Confirm the actual 90-degree turn for the elbow being considered. A product photograph should not replace the selected-fitting dimensions used for layout decisions.

Specify both end sizes and the Sch40 wall

Give the nominal size, actual outside diameter and wall thickness at each end. State whether the connection diameters must be equal or whether a reducing arrangement is required. Confirm how the selected size option maps to those measurements. Define the connection form and preparation for both ends, together with the mating pipe walls and the governing dimensional standard.

Confirm WPB scope before assessing service

For the Carbon Steel configuration, state the exact ASTM A234 WPB requirement and request material confirmation for that same elbow. A Stainless Steel choice needs its own grade specification. Include design pressure, temperature and the service medium when asking for construction and suitability evidence. Schedule 40 describes a dimensional requirement and does not independently establish pressure capacity. Review the selected drawing and material, construction and pressure-temperature documentation before accepting the fitting for the intended compact piping turn.
