45-Degree Butt-Weld Elbow for Industrial Piping

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This industrial piping listing names a 45-degree butt-weld elbow with an ASME B16.9 reference. The actual variant identifies Carbon Steel. Welding wording appears in the table, but so does NPT, so confirm the connection specification before selecting the elbow for installation.

Confirm the direction change and actual ends

Provide the required angle, bend radius and center-to-end dimensions together with the mating pipe details. Ask the supplier to reconcile the butt-weld description and NPT field on the actual drawing. Those connection descriptions should not be treated as interchangeable or as a confirmed dual-end configuration.

Select the exact pipe size within the 1/2–12 inch option range, then define outside diameter, wall or schedule, bore and tolerances. The repeated range in the length, height and mounting-hole fields does not provide separate measured dimensions. Confirm end preparation using the selected piping and joint specification.

Review material and dimensional acceptance

Identify the applicable ASME B16.9 edition and requirements for the proposed elbow. Obtain the actual carbon steel grade, material condition, traceability and required inspections. The FORGED label describes source wording rather than proving the manufacturing route or material conformity of the supplied part.

The table lists Low Pressure and Not Rated without a numerical allowable envelope. Describe the process fluid, pressure, temperature, cycles and relevant loads or supports. Review the fitting and its joints against the construction project requirements instead of treating the application label as service qualification.

Complete the installation supply enquiry
