WPB Carbon Steel Long-Radius Butt-Weld Elbow

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  150
• Application

  Construction Engineering
  Thread Types

  NPT

This WPB carbon steel long-radius butt-weld elbow is listed for construction with A234 and B16.9 references. The title includes forged and seamless wording, and the table records Class 150. Select an individual size from the half-inch to 12-inch option and confirm the supply scope.

Complete the long-radius elbow drawing and size selection

Specify the actual bend angle, radius, wall thickness or schedule and tolerances. Long-radius wording does not select the angle or wall. Confirm the nominal size convention and mating pipe dimensions for the ordered size instead of treating the broad range as finished geometry.

Request actual length, height and hole measurements because these fields repeat the range. Clarify how the Hexagon head code applies to the component. The approved drawing should distinguish flow geometry from any code or feature reference that remains unexplained.

Verify WPB supply, standard scope and end preparation

Obtain the full selected material designation and condition, certificates and traceability. Identify the governing A234 and B16.9 documents, editions and conformity scope. Request records supporting forged and seamless supply descriptions rather than treating title references as completed manufacturing or compliance evidence.

Allocate the butt-weld title and NPT table reference through an end schedule. Agree preparation, applicable full thread details, mating interfaces, sealing and examination. Define measurable smooth-surface acceptance and delivery protection alongside the dimensional and material inspection requirements.

Confirm the Class 150 basis for construction conditions
