MULTI CORE+ EARTH CONTROL, 0.6/1kV ARMOURED PVC V90 (1.5mm²)CONTROL CABLES
PVC INSULATED PVC BEDDED STEEL WIRE ARMOURED AND PVC SHEATHED CABLE TO AS/NZS 5000.1
CABLE APPLICATION
Description
For control circuits unenclosed, enclosed in conduit, buried direct or in underground ducts for commercial, industrial, mining and electricity authority systems where mechanical protection is required.
CABLE DESIGN
Conductor
Plain Annealed Copper Conductor to AS/NZS 1125
Insulation
V90 PVC to AS/NZS 3808
Colours: White Cores (numbered), Green/Yellow
Sheath
5V-90 PVC to AS/NZS 3808
Colours: Orange or Black
CHARACTERISTICS
|
Conductor |
Cable |
||||||||
|
No. of Core |
Nom. Area mm² |
No. & Dia. of Wires No./mm |
Nom. Dia. mm |
Nom. Insulation Thickness mm |
Nom. Dia. Under Armour mm |
Dia of Wire mm |
Nom. Dia. Over Armour mm |
Nom. Overall Dia. mm |
Approx. Mass Kg/100m |
|
2C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
8.9 |
0.9 |
10.7 |
14.4 |
39.7 |
|
3C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
9.7 |
0.9 |
11.5 |
15.2 |
44.5 |
|
4C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
10.6 |
0.9 |
12.4 |
16.1 |
59.2 |
|
6C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
11.5 |
0.9 |
13.3 |
17.0 |
67.5 |
|
8C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
13.7 |
1.25 |
16.2 |
19.9 |
84.0 |
|
10C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
15.1 |
1.25 |
17.6 |
21.3 |
90.2 |
|
12C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
15.9 |
1.25 |
18.4 |
22.1 |
112.0 |
|
15C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
16.8 |
1.25 |
19.3 |
23.0 |
122.6 |
|
16C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
17.7 |
1.25 |
20.9 |
24.6 |
127.7 |
|
20C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
18.6 |
1.6 |
21.8 |
25.5 |
142.0 |
|
25C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
21.3 |
1.6 |
24.5 |
28.4 |
166.3 |
|
30C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
23.0 |
1.6 |
26.2 |
30.1 |
185.0 |
|
40C+E |
1.5 |
7/0.50 |
1.5 |
0.8 |
27.4 |
2.0 |
31.4 |
35.7 |
254.8 |
