High Quality Flanged Flexible Pipe Settlement Joint
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
Product description
-
warranty1yearcustomized supportOEM, ODM
-
model numberSJ100TechnicCasting
-
ConnectivityFlangeshapeEqual
-
head codeRoundOverall LengthAccording to pipeline requirements
-
HeightAccording to pipeline requirementsSurface TreatmentCleaning Supplies
-
System of MeasurementinchMounting hole diameterAccording to pipeline requirements
-
Pipe ClassNot RatedApplicationAgricultural Irrigation, Construction Engineering, Shipbuilding, petrochemical industry
-
Size1. 1/2inch ~ 72inchWorking Pressure6 ~ 25 bars
-
Axial movement100 ~ 400 mmDeflection angle± 15 °
-
Rubber protection sleeveSupportCoating300um FBE
-
Hydro testSupportEccentricity testSupport
-
CertificateISO 9001Product nameDuctile iron and carbon steel flexible pipe settlement joint
