Galvanized SCH40 Steel 45-Degree Elbow

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This construction listing describes a galvanized steel 45-degree elbow with an SCH40 reference. Carbon Steel is the actual selectable material, while welded and NPT end descriptions also appear. Confirm the supplied dimensions, surface treatment and connection before agreeing the component specification.

Set the 45-degree geometry and wall requirements

Provide nominal size, outside diameter and the actual wall dimensions required for the selected schedule. SCH40 does not supply one universal wall thickness across the size range. Define bend radius, angle and center-to-end dimensions on the approved drawing for the proposed pipe connection.

The 1/2–12 inch option and its repetition under length, height and mounting-hole diameter are not actual measurements. Clarify Hexagon wording against the elbow geometry. Confirm the selected size and configuration are available before using the broad range to prepare the purchase order.

Agree galvanizing and end acceptance

Request the galvanizing process, covered surfaces, relevant thickness and inspection criteria. The title does not supply treatment records, and smooth or corrosion resistant wording does not establish performance. Agree measurable surface acceptance and preservation requirements for the actual supplied component.

Resolve the welded reference and NPT table entry with an end drawing and mating-pipe requirements. Specify the applicable preparation or thread inspections rather than assuming one installation arrangement. Obtain the carbon steel grade, condition and traceability, with manufacturing evidence supporting the recorded FORGED description.

Review construction duty and inspection records

Describe the medium, contaminants, external exposure, pressure, temperature, transients, cycles and loads. Low Pressure and Not Rated leave allowable numerical limits unspecified. Assess the selected elbow and joint under the project requirements, then confirm material, galvanizing, dimensional and end records, marking, preservation, quantity and delivery. Agree OEM requests and warranty terms separately from technical acceptance.
