X52 PSL1 ERW Carbon Steel Pipe for Onshore Pipelines
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
-
InvoicingBy Actual WeightOiled or Non-oiledNon-oiled
-
Section ShapeRoundSurface TreatmentCold Rolled
-
Tolerance±1%Alloy Or NotNon-Alloy
-
ApplicationFluid Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, Oil PipeCertificateAPI , ISO 9001
-
Delivery Time8 ~ 14 daysGradecarbon steel
-
Outer Diameter219 - 1066 mmSpecial PipeAPI Pipe, Other, EMT Pipe, Thick Wall Pipe
-
StandardASTMTechniqueERW
This onshore pipeline enquiry identifies ERW carbon steel pipe with X52 PSL1 wording under API 5L. The table gives a generic carbon steel grade, and actual variants select thickness and length. Confirm that the offered material and documentation match the named grade and specification level.
Verify the X52 PSL1 supply requirements
Request the applicable API 5L edition, actual grade and product specification level, with material traceability and the required chemical, mechanical and weld inspection records. High Strength wording supplies no measured property or capacity. The catalogue title does not independently certify the selected pipe.
ASTM also appears without a numbered specification. Clarify its intended role rather than assuming an equivalent grade or dual conformity. The supplier should explain the recorded ERW and cold-rolled processing sequence, supply condition and acceptance evidence for the actual pipe.
Match dimensions to the onshore pipeline design
Choose an exact outside diameter, wall thickness and delivery length. The table lists 219–1066 mm diameter, while the variants pair a 6–20 mm thickness entry with 6 m or 12 m length. Confirm availability of the selected combination and establish end preparation, straightness and ovality requirements.
Determine the measurement covered by ±1% and its inspection basis. Include the actual transported medium, pressure, temperature, cycles and installation loads. External exposure, burial or support conditions should inform protection and project assessment rather than being inferred from the word onshore.
Agree inspection, preservation and delivery
The drill-pipe label represents another proposed role requiring its own technical review, not automatic interchangeability with line pipe. Obtain any required certificate scope, joint inspection and acceptance records. Non-oiled supply needs agreed preservation, storage and protective treatment where specified. Reconfirm actual-weight invoicing and the listed 8–14-day delivery wording for the chosen order.
Technical information for every product inquiry
Prepare the requirement before final product confirmation.
The product page is a starting point. Drawings, samples, interfaces, materials, quantities and acceptance requirements are reviewed before stock matching or custom production is confirmed.
Discuss this product in your project context.
Share the available drawing, sample, reference, target quantity and application information. Unknown items can remain open for review.
