Long-Radius Butt-Weld Steel Elbow Angle and Grade Enquiries
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
-
warranty1 yearcustomized supportOEM, ODM
-
model numberelbowTechnicCasting
-
ConnectivityFemaleshapeEqual
-
head codeSquareOverall Length4 in
-
Height2Surface TreatmentPainting
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.2 inPipe FeaturesFlexible, Corrosion-resistant, Chemical Resistant, Uv Resistant, No additional Features, underground rated
-
Pipe Class125Applicationpetrochemical industry, Shipbuilding, Construction Engineering, Power Industry, Heating Systems
-
Thread TypesNPT
A long-radius butt-weld elbow enquiry should name one required angle and one material grade. Define those choices explicitly before confirming the end geometry and construction for a Stainless Steel or Carbon Steel configuration.
Choose the actual turn from the angle requirements
State the required 45-, 60-, 90- or 180-degree turn and provide its centerline radius on a piping drawing. Include both end positions and the surrounding clearance requirements. Confirm the selected angle and long-radius geometry for the material and size being considered. A group of angle labels does not establish a verified angle choice for every variant, and a curved reference part cannot provide measured routing dimensions.
Give the steel specification one precise grade
Identify the applicable material specification and required grade for the elbow. WPB, WP11 and A105 should be stated as distinct project requirements rather than treated as interchangeable names. Confirm the selected grade for the intended steel family and construction. Include any B16.9 requirement with the relevant edition and dimensional scope, so the material discussion refers to the same elbow geometry that the pipe route needs.
Confirm both weld ends and construction together
Provide the pipe dimensions, wall thickness and butt-weld preparation at each end. Identify any female or thread requirement separately and confirm the actual connection arrangement for the supplied part. A seamless-construction requirement should also be confirmed for that configuration, with relevant material and inspection documentation. Include the medium and design pressure and temperature for the rating review. The final elbow request should bring one angle, one grade, both connections and the construction requirement together before service suitability is accepted.
Technical information for every product inquiry
Prepare the requirement before final product confirmation.
The product page is a starting point. Drawings, samples, interfaces, materials, quantities and acceptance requirements are reviewed before stock matching or custom production is confirmed.
Discuss this product in your project context.
Share the available drawing, sample, reference, target quantity and application information. Unknown items can remain open for review.
