Carbon Steel Eccentric Butt Weld Reducer | A106 Enquiry
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.25 in
-
Pipe Class1000SizeCustomized Size
-
Product nameElbow
An eccentric reducer enquiry should describe the transition between two pipe sizes and the required relationship between their centres. Begin with a drawing of the selected reducer, then connect its dimensions and material records to the intended pipeline. Clarify the scope of any material-standard reference before using it to assess the finished fitting.
Show the End Pair and Eccentric Alignment
Give the nominal sizes, outside diameters and wall thicknesses of both mating pipes. Request the reducer length and a drawing showing the required end-centre offset and alignment. One size label cannot identify the complete reducer pair. State the planned installation orientation and any flow or drainage requirement that the project needs assessed; have the selected drawing and design review establish the appropriate arrangement for that application.
Clarify the Steel Specification and Manufacturing Record
Name the exact material grade and applicable specification edition. Where A106 is referenced, identify which material or product that reference is intended to cover and define the requirements for the finished fitting separately. Obtain traceable material records and production documentation for the quoted component. If forged construction is required, include that requirement explicitly and request supporting evidence. Define the butt-weld preparation at each end against the corresponding pipe thickness and joint detail.
Establish the Transition's Documented Design Limits
Identify the dimensional and pressure-design standards governing the reducer and completed joints. Provide the fluid, operating pressure and temperature together with fabrication and installation requirements. Ask for records supporting the selected geometry, grade and duty scope. An undefined class number does not establish an operating-pressure rating, and surface appearance does not qualify a coating for service. Complete the enquiry with the approved offset drawing, end pair, walls, material-reference scope, production evidence and documented design limits.
Technical information for every product inquiry
Prepare the requirement before final product confirmation.
The product page is a starting point. Drawings, samples, interfaces, materials, quantities and acceptance requirements are reviewed before stock matching or custom production is confirmed.
Discuss this product in your project context.
Share the available drawing, sample, reference, target quantity and application information. Unknown items can remain open for review.
