ASME B16.9 ASTM A234 WPB 45-Degree DN80 Pipe Elbow Enquiry

• warranty

  1 year
  customized support

  OEM, ODM, OBM
• model number

  elbow 3017
  Technic

  Forged
• Connectivity

  Welding
  shape

  Equal
• head code

  ellipsoidal head
  Overall Length

  4 in
• Height

  4
  Surface Treatment

  Smooth
• Pressure

  Low Pressure
  System of Measurement

  inch
• Mounting hole diameter

  0.25 in
  Pipe Features

  Flexible
• Pipe Class

  125
  Application

  Agricultural Irrigation, Automotive Repair, Heating Systems
• Thread Types

  NPT

This pipe elbow enquiry concerns a 45-degree DN80 layout with ASME B16.9 and ASTM A234 WPB requirements. Confirm the actual turn, radius, end dimensions and material of the selected configuration before matching it to the pipe run. The enquiry should describe the required geometry clearly enough to distinguish it from a different angle or nominal size.

Locate the 45-degree turn on the pipe layout

Show the incoming and outgoing pipe centerlines and identify the required change in direction. Add the centerline radius and center-to-end dimensions needed for the installation. Request a drawing that confirms those features for the selected elbow. Keep the DN80 designation linked to actual end diameters and walls; a smaller millimetre size label should not be treated as equivalent without dimensional confirmation.

Separate the WPB requirement from material choices

Specify ASTM A234 WPB for the intended Carbon Steel configuration and request the corresponding material documentation. A Stainless Steel choice needs its own exact material specification and assessment. State the required ASME B16.9 edition and wall requirement on the same enquiry. Confirm the actual construction and end preparation instead of assuming these are established by a broad material family or a general elbow photograph.

Check both connections and the service scope

Provide the dimensions of both adjoining pipes and identify the joining preparation required at each end. Review the resulting connection against the installation procedure and layout drawing. Include the intended medium, pressure and temperature when requesting qualification for the selected configuration. Neither a nominal diameter nor a turn angle establishes an operating rating. Complete the enquiry with the selected-part drawing, material scope and wall definition so the geometry and service conditions can be evaluated together before the elbow is accepted.
