DIN ANSI Forged Steel Resistant Flexible Anti-vibration Rubber Joint Compensator Flange Connection for Oil Gas Water Supply
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
Product description
-
warranty1 Yearcustomized supportOEM, ODM
-
model numberREJTechnicForged
-
ConnectivityFlangeshapeEqual
-
head codeRoundSurface TreatmentCleaning Supplies
-
Mounting hole diameterAccording to pipeline requirementsPipe ClassNot Rated
-
Applicationwater supply and drainage systems, natural gas transportation, oil & gas industry, plumbing & water supplyProduct nameFlexible Anti-vibration Compensator Bellow Rubber Joint
-
Nominal DiametersDN15-DN4000Working temperature-15~+80 ℃ (special:-30~+150℃ )
-
Rubber joint material:EPDM,NBR,CR,PTFE,etc.Flange materialSS,CS,CS galvanized,ductile iron,PPH (PN10, PN16)
-
Flange standardDIN PN10,PN16,PN25/ANSI 150LB,300LB/JIS 10K,etc.Test pressure1.5 times of working pressure
-
Explosion pressure2 times of working pressureCertificateISO, TUV, WRAS, CO, MTC, etc
-
ManufacturerYes, factory add: Gongyi City,China
Technical information for every product inquiry
Prepare the requirement before final product confirmation.
The product page is a starting point. Drawings, samples, interfaces, materials, quantities and acceptance requirements are reviewed before stock matching or custom production is confirmed.
All technical resourcesChoose the product-family route that matches your question.
Drawings and tolerancesOrganize dimensions, units, datums and critical features.
Inspection recordsPlan what must be checked and how results can be recorded.
Supplier evaluationReview capability, communication, traceability and repeatability.
RFQ to deliveryFollow the requirement through quotation, sample and order planning.
Discuss this product in your project context.
Share the available drawing, sample, reference, target quantity and application information. Unknown items can remain open for review.
