Large Diameter Adjustable Telescopic Dismantling Joint Expansion Joint for Water Pipeline Connection
For industrial sourcing
Prepare a clearer RFQ
Include the details below so RELIA can understand the part and discuss the next step with you.
- Drawing, sample, or reference standard
- Material grade and preferred process
- Dimensions, tolerances, and surface finish
- Application, target quantity, and destination
Production timing, packing, and shipping terms are confirmed for each project after specifications and trade terms are agreed.
Product description
-
warranty1 yearscustomized supportOEM, ODM
-
model numberDJTechnicForged
-
ConnectivityFlangeshapeEqual
-
head codeRoundOverall LengthAccording to requirements
-
HeightAccording to requirementsSurface TreatmentAccording to requirements
-
System of MeasurementinchMounting hole diameterAccording to requirements
-
Pipe ClassAccording to requirementsApplicationwater supply and drainage systems, plumbing & water supply, building water supply and drainage
-
Product nameLarge Diameter Adjustable Telescopic Dismantling Joint Expansion JointNominal DiametersDN65-DN3200
-
Working pressurePN10 - PN40Body MaterialStainless steel,carbon steel,ductile iron
-
Working temperature-10°C ~+ 70°CDrawingOffer
-
Flange standardDIN PN10,PN16,PN25/ANSI 150LB,300LB/JIS 10K,etc.Sealing ring materialNBR,EPDM etc.
-
Applicable mediaDrinking water ,etc.CertificateISO, TUV, WRAS, CO, MTC, etc
