A234 WPB SCH40 Concentric / Eccentric Pipe Reducer Enquiry
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.17 in
-
Pipe Class150SizeCustomized Size
-
Product nameElbow
This SCH40 reducer enquiry combines Stainless Steel and A234 Wpb title wording with concentric and eccentric alternatives. Actual variants select broad material and one millimetre size, without exact-grade or centreline options. Reconcile the selected material and transition drawing before assigning either metallurgy or reducer geometry from the title.
Resolve the material wording through traceable records
Ask which complete material specification and exact grade apply to the offered reducer, supported by records linked to the selection. Do not certify the combined Stainless Steel/A234 Wpb wording, choose a replacement standard or infer metallurgy from gallery finishes. Stainless Steel, Alloy and Carbon Steel choices require their own assignments. Clarify the applicable material and dimensional requirements with editions and inspection evidence.
Choose concentric or eccentric geometry with both ends defined
Confirm large and small nominal sizes, actual outside diameters and walls, transition length, taper and centreline relationship. Resolve the Equal entry before assigning unequal-end geometry. The supported reducer family differs from the imported Elbow table name. Each single millimetre option needs mapping to both ends; the half-inch to seventy-two-inch title span does not prove supplied capacity. Map SCH40 to the selected sizes and actual measured walls. Gallery shapes do not assign subtype to a variant.
Qualify the welded transition and actual operating duty
Define end preparation, alignment and inspection for both adjoining pipes, including offset orientation if the selected reducer is eccentric. Support Forged with production records and clarify coating and weld-zone condition beyond Painting. Generic Hexagon and mounting-hole fields are not transition dimensions. Establish the basis behind Pipe Class 150, then assess fluid, pressure, temperature, corrosion and loads for the reducer, pipes and completed welds. Customized Size alone does not establish offered dimensions; accept against reconciled material, geometry and joining evidence.
すべての製品照会に必要な技術情報
製品の最終確認前に要件を整理します。
製品ページは出発点です。在庫適合や特注生産の確定前に、図面、サンプル、接続、材質、数量、受入要件を確認します。
案件の条件に沿ってこの製品を検討します。
現在の図面、サンプル、参照品、数量、用途情報をお送りください。不明点は未確定のまま検討できます。
