Steel Tee for Marine and Desalination Systems
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
warranty1 Yearcustomized supportOEM
-
TechnicFORGEDConnectivityWelding
-
shapeEqualhead codeHexagon
-
Overall LengthCustomized SizeHeightCustomized Size
-
Surface TreatmentPlainPressureHigh Pressure
-
System of MeasurementMetricMounting hole diameterCustomized Size
-
Pipe FeaturesOtherPipe ClassOther
-
ApplicationOtherThread TypesCustomized Size
This marine engineering and desalination listing describes a steel tee with ASTM A815 and S32205 duplex references. The original image supports a tee form, but the selectable types are labeled Reducer and the materials are Carbon Steel and a234wpb. Confirm the actual supplied component and material before procurement.
Resolve the ordered tee and material package
Obtain the drawing identifying the proposed tee and its relationship to the selectable option. The visual form does not establish a verified variant, dimensions or supplied grade. Request material records to resolve the duplex designation against the carbon steel and WPB option labels.
Specify the actual grade, condition, traceability and inspection requirements, including the applicable ASTM specification and edition. Image markings and title references do not replace the supplied documentation. Confirm the manufacturing records required to support the Forged description rather than assuming a production certificate is included.
Define run, branch and welded ends
Provide run and branch sizes, outside diameter, wall thickness, center-to-end dimensions and end preparation on the selected drawing. Equal and Hexagon wording does not provide measured geometry. Agree the welding and inspection requirements for the actual connection and mating pipe.
The 1/2–110 inch range is broad listing information; confirm the exact configuration and availability. Customized Size fields and Metric wording require agreed dimensions and units. Define the intended surface and acceptance criteria beyond Plain, and connect dimensional, end and finish inspections to the approved purchase specification.
Assess the desalination or marine process
Describe seawater, brine or other process composition, treatment and cleaning chemicals, contaminants, pressure, temperature and cycles. High Pressure and Other class provide no numerical allowable rating. Review the selected material and joint without assuming seawater approval or corrosion immunity. Confirm records, marking, preservation and delivery, with OEM and warranty terms agreed separately.
すべての製品照会に必要な技術情報
製品の最終確認前に要件を整理します。
製品ページは出発点です。在庫適合や特注生産の確定前に、図面、サンプル、接続、材質、数量、受入要件を確認します。
案件の条件に沿ってこの製品を検討します。
現在の図面、サンプル、参照品、数量、用途情報をお送りください。不明点は未確定のまま検討できます。
