ASME B16.9 Carbon Steel Butt-Weld Reducing Pipe Tee Enquiry

• warranty

  1 year
  customized support

  OEM, ODM
• model number

  tee 1706
  Technic

  Casting
• Connectivity

  Male/Female
  shape

  Equal/Reducing
• head code

  Hexagon/Round
  Overall Length

  4.8 in
• Height

  7
  Surface Treatment

  Painting
• Pressure

  Low Pressure
  System of Measurement

  inch
• Mounting hole diameter

  0.25 in
  Pipe Features

  Flexible, Corrosion-resistant, Uv Resistant, Chemical Resistant
• Pipe Class

  Not Rated
  Application

  petrochemical industry, Shipbuilding, Construction Engineering, Power Industry
• Thread Types

  NPT

This reducing pipe tee enquiry addresses an ASME B16.9 butt-weld requirement with a carbon steel material request. Identify the main run and smaller branch separately before evaluating the selected fitting. The enquiry needs three connection specifications and the branch relationship, rather than one size label applied to the whole tee.

Describe the main run and smaller branch

Mark the run direction and branch orientation on the piping drawing. Give the nominal size, actual diameter and wall for each opening, together with the center-to-end dimensions required by the layout. Confirm which port forms the reducing branch and how it relates to the two run ends. General tee images may show different branch proportions, so the selected drawing is needed to establish the actual size relationship.

Check three butt-weld connection requirements

State the required ASME B16.9 edition and end preparation, then request confirmation for all three connections. Compare them with the adjoining pipes and the joining procedure. A general male or female label does not identify the weld-end geometry needed by a specific installation. Keep the wall requirement and end preparation associated with each opening so that the branch and run can be assessed together.

Define the selected material and service conditions

Specify the exact Carbon Steel grade for the enquiry and obtain the corresponding material and construction documentation. A Stainless Steel option needs its own specification. Include the medium, design pressure and temperature when asking for the selected tee's qualification scope. Neither a qualitative pressure label nor a general industry application establishes an operating rating. Before acceptance, confirm the run-to-branch pair, three end dimensions and material scope against the project drawing, then evaluate the proposed branch connection under the stated service conditions.
