B16.9 Butt-Weld Concentric Reducer for 2-Inch Enquiries
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
model numberreducer 3697TechnicForged
-
ConnectivityFemaleshapeEqual
-
head codeHexagonOverall Length4 in
-
Height4Surface TreatmentPainting
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.2 inPipe FeaturesFlexible
-
Pipe Class125Applicationpetrochemical industry, Power Industry, Construction Engineering, Shipbuilding, Heating Systems
-
Thread TypesNPT
A two-inch concentric reducer enquiry should identify which end carries the named pipe size. Define the other end and the required centerline relationship before confirming a material, wall or construction requirement for the proposed transition.
Complete the size pair behind the two-inch request
State the nominal designation and actual dimensions of the large and small ends, with units included. Identify whether the two-inch requirement applies to the larger or smaller pipe interface. A single size label does not describe the full transition, so the two ends should appear together on the reducer drawing. Confirm the required concentric alignment and the transition length for that same dimensional pair.
Specify the butt-weld geometry at both ends
Provide the wall thickness and end preparation needed at each mating pipe. Confirm the actual connection form rather than treating a female or thread descriptor as equivalent to butt-weld preparation. The reducer profile should be reviewed with the two pipe interfaces and available layout space. Reference images of different transition profiles can help communicate the family, but cannot establish the alignment or dimensions of the requested part.
Confirm B16.9 and construction with the selected steel
Choose Stainless Steel or Carbon Steel and name the required grade explicitly. State the applicable B16.9 edition and any seamless-construction requirement for confirmation on the proposed reducer. Include the medium and design conditions when requesting material, construction and rating documentation for that configuration. The final transition enquiry should connect the complete end pair, concentric alignment, wall and material specification before dimensional fit or service suitability is accepted.
すべての製品照会に必要な技術情報
製品の最終確認前に要件を整理します。
製品ページは出発点です。在庫適合や特注生産の確定前に、図面、サンプル、接続、材質、数量、受入要件を確認します。
案件の条件に沿ってこの製品を検討します。
現在の図面、サンプル、参照品、数量、用途情報をお送りください。不明点は未確定のまま検討できます。
