90-Degree Long-Radius Butt-Weld Elbow for Construction

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This 90-degree long-radius butt-weld elbow is listed for construction with stainless 304/316L and PN16 title wording. Its actual variant states Carbon Steel and a half-inch to 12-inch range. Resolve the material and rating records before selecting a component for the project.

Clarify the material and PN16 supply basis

Request the complete supplied material designation and condition, supported by certificates and traceability. The stainless title and carbon option do not establish one approved grade. Keep the recorded variant while obtaining written confirmation rather than choosing an apparent stainless alternative or changing the option.

Clarify PN16 in the title against Not Rated in the table. Obtain the actual governing rating document and material/temperature basis without converting the number into operating pressure. Confirm the governing supply specifications and conformity scope; no numbered component standard is selected here.

Approve the bend dimensions and connection schedule

Select one nominal size and reconcile the DN wording with the inch range. Specify the actual long radius, wall thickness, tolerances and matching pipe dimensions for the 90-degree elbow. Request finished length, height and hole dimensions and explain the Hexagon code instead of copying range entries.

Allocate the butt-weld title and NPT table entry to individual ends with preparation, applicable full thread details, mating parts, sealing and examination. Obtain evidence for the forged and seamless supply descriptions. Define measurable smooth-finish acceptance and protection during delivery.

Verify construction operating and corrosion conditions

State the actual medium composition, numerical pressure and temperature envelope, cycles, exposure and external loads. Low Pressure does not define these requirements. Evaluate corrosion suitability against the selected material and environment and obtain the relevant joint and rating evidence. Agree the resolved material, drawing, interfaces and inspection/testing package before project acceptance.
