Carbon Steel Pipe with Polyurethane Foam and HDPE
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
InvoicingBy Actual WeightOiled or Non-oiledNon-oiled
-
Section ShapeRoundSurface TreatmentHDPE Coating
-
Tolerance±1%Alloy Or NotNon-Alloy
-
ApplicationFluid Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, Oil PipeCertificateAPI , ISO 9001
-
Delivery Time8 ~ 14 daysGradeP235JH
-
Outer Diameter219 - 1066 mmProcessing ServiceWelding, Punching, Cutting, Bending, Decoiling
-
Special PipeAPI Pipe, Other, EMT Pipe, Thick Wall PipeStandardASTM
-
TechniqueSaw
This carbon steel pipe combines polyurethane foam insulation with HDPE outer protection in the product title. The table records P235JH and Saw technique. Treat the entry as an assembly enquiry: the steel carrier, insulation and outer protection need one coordinated specification for the selected service.
Allocate dimensions to the carrier and outer protection
Listed outside diameter spans 219–1066 mm, while thickness options cover 6–20 mm with 12 m or 6 m lengths. Establish which layer each dimension describes. Request carrier outside diameter, bore and wall, foam and HDPE thicknesses, finished diameter and a drawing for the actual configuration.
Assign ±1% tolerance to named dimensions and inspection methods. Obtain the complete P235JH designation, material condition, governing documents and editions, heat traceability and certificates. Generic ASTM wording leaves the precise specification open. Confirm the SAW weld route, seam arrangement and inspection records without assuming other manufacturing routes.
Specify polyurethane foam and HDPE interfaces
Define the layer construction, coverage, interfaces and end treatment. Agree joint assembly, field-joint insulation and outer closure, inspection and repair details. Obtain thermal performance records with their stated conditions; this listing provides no foam density, conductivity, operating temperature or predicted service life.
Processing options in the table require confirmation for the selected stage of manufacture. Cutting or bending a completed layered assembly needs an agreed method and acceptance criteria. Plan transport, lifting, support and storage around the actual construction and exposed pipe ends.
Match the complete assembly to its service
Provide medium composition, pressure, temperature, cycling, exposure and loads for the intended installation. Obtain compatibility and acceptance records for steel, welds, foam, HDPE and joints together. Verify relevant API/ISO 9001 documents and agree testing, dimensional and layer reports, traceability and quotation scope.
