FBE Coated Steel Pipe with Dual Seal Socket
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
InvoicingBy Theoretical WeightOiled or Non-oiledSlightly Oiled
-
Section ShapeRoundSurface TreatmentGalvanized
-
Tolerance±10%Alloy Or NotNon-Alloy
-
ApplicationFluid Pipe, Boiler Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, Oil Pipe, Chemical Fertilizer Pipe, Structure PipeCertificateAPI , CE, ISO 9001
-
Delivery Time31 ~ 45 daysGradecarbon
-
Outer Diameter150 - 350Processing ServiceWelding, Punching, Cutting, Bending, Decoiling
-
Special PipeAPI Pipe, EMT Pipe, Thick Wall PipeStandardASTM
This FBE-coated steel pipe with dual-seal socket enquiry targets underground and marine pipeline applications. The table also lists a galvanized surface, so the actual coating construction needs clarification. Confirm the finished pipe and seal system before treating the title performance wording as an accepted specification.
Distinguish FBE from the galvanized surface entry
Ask whether FBE, galvanizing or a documented multi-layer arrangement is proposed. Do not assume the catalogue establishes a combined system. Obtain substrate preparation, internal/external coverage, coating thickness, cure, adhesion and inspection criteria, together with a suitable field-joint and repair procedure.
Request the full steel designation, applicable ASTM document and edition, manufacturing route, condition and traceability. Carbon and Non-Alloy are broad records rather than a complete material specification. API/EMT/Thick Wall labels and the processing-service list require allocation to the actual supplied pipe.
Allocate dimensions and dual-seal joint performance
All three variants pair thickness 1.2 with lengths 12 m, 6 m or 6.4 m. Thickness and the outer-diameter range 150–350 lack units. Obtain the selected dimensions explicitly and clarify which property the ±10% tolerance covers, including agreed wall, length, roundness and straightness acceptance.
Require socket and seal drawings covering engagement, insertion depth, seal material, joint tolerances and assembly. Confirm allowable movement and the proposed joint test. Dimensional fit alone does not establish pressure performance, chemical compatibility or durability under the intended installation conditions.
Assess burial or marine exposure individually
Provide medium, pressure, temperature, cycling, soil or seawater exposure, loads and installation requirements. High Pressure and corrosion-resistant wording supply no numerical approval. Verify the applicable scope of API, CE and ISO 9001 documents, then agree handling, support, joint/coating inspection, marking, records and quotation scope.
すべての製品照会に必要な技術情報
製品の最終確認前に要件を整理します。
製品ページは出発点です。在庫適合や特注生産の確定前に、図面、サンプル、接続、材質、数量、受入要件を確認します。
案件の条件に沿ってこの製品を検討します。
現在の図面、サンプル、参照品、数量、用途情報をお送りください。不明点は未確定のまま検討できます。
