Galvanized Cast Carbon Steel Female NPT Coupling
産業調達向け
明確なRFQを準備
RELIAが部品内容を理解し、次のステップを協議できるよう、以下をご提示ください。
- 図面、サンプル、または参照規格
- 材質グレードと希望製法
- 寸法、公差、表面処理
- 用途、予定数量、納入先
製造納期、梱包、出荷条件は、仕様と取引条件の合意後に案件ごとに確定します。
-
warranty1 yearcustomized supportOEM, ODM
-
TechnicCastingConnectivityOther
-
shapeReducinghead codeOther
-
Overall Length4 inSurface TreatmentSmooth
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.26 inPipe FeaturesFlexible, Corrosion-resistant, Chemical Resistant, Uv Resistant, No additional Features, underground rated
-
Pipe Class3000ApplicationAgricultural Irrigation, Automotive Repair, Heating Systems, Power Industry, Construction Engineering, Shipbuilding, petrochemical industry
-
Thread TypesNPT
This galvanized cast carbon steel coupling is listed with female NPT threading, weld wording and half/full configurations. The single variant is 10 mm carbon steel. Select the actual arrangement and interface schedule before assigning the coupling to a project or finalizing the quotation.
Specify the half or full arrangement and interfaces
Provide a drawing identifying connection count, nominal ends, wall and tolerances. Clarify the Reducing entry and confirm whether a half or full coupling is required and available. The generic variant does not establish both configurations for the selected order.
Allocate weld and female NPT wording to actual ends. Define welding preparation where relevant and the complete thread designation, engagement, mating parts, sealing and examination. Confirm the role of the 10 mm size against the inch dimensional system, 4 in length and 0.26 in hole, with installation clearance.
Define galvanized casting and material acceptance
Specify the complete carbon steel designation, condition, governing ASTM document and edition. Obtain traceability, casting and inspection records for the component. Identify the selected B16.11 requirements and conformity evidence; general standard references and casting wording do not establish certification.
Agree the galvanizing method, coating coverage and thickness criteria, together with measurable Smooth surface requirements. Define coating and thread inspection, handling protection and delivery acceptance. The finish descriptions do not establish corrosion lifetime or suitability for every environment.
Confirm Class 3000 and environmental duty evidence
State the governing rating basis at the actual material and temperature rather than treating the class number as operating pressure. Provide medium, numerical duty, cycling, corrosion exposure and loads. Clarify which feature claims apply, including any buried installation, and obtain relevant flexibility, chemical or UV evidence. Document material/joint acceptance with the selected drawing, casting, interfaces, coating and testing package.
すべての製品照会に必要な技術情報
製品の最終確認前に要件を整理します。
製品ページは出発点です。在庫適合や特注生産の確定前に、図面、サンプル、接続、材質、数量、受入要件を確認します。
案件の条件に沿ってこの製品を検討します。
現在の図面、サンプル、参照品、数量、用途情報をお送りください。不明点は未確定のまま検討できます。
