45° Pipe Elbow for Oil and Gas Piping

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This 45-degree elbow listing presents an oil/gas piping enquiry with conflicting material information. The title names stainless steel304/316L, but the sole actual variant specifies Carbon Steel. Resolve that discrepancy before treating either material or grade as the supplied component’s certified identity.

Reconcile alloy and manufacturing information

Request corrected selected configuration records, the full material specification, grade, condition, traceability and certificate. The title’s ASTM reference lacks a document number. Agree the actual governing material and dimensional documents rather than supplying an assumed A234 or A403 specification.

Obtain manufacturing records allocating forged and welded descriptions to the actual item. Define surface inspection and any protective treatment. Smooth and anti-corrosion wording do not identify a coating or establish compatibility with the proposed oil, gas or other medium.

Confirm the 45-degree elbow arrangement

Ask for actual radius, center-to-end dimensions, outside diameters, bores, wall thickness and tolerances. Eccentric/concentric wording does not establish a reducing pair or offset arrangement on its own. If unequal ends are required, specify both sizes and their geometry explicitly on the drawing.

Resolve Welding versus NPT entries through the supplied end design and mating pipe details; do not assume a hybrid. Clarify Hexagon and the repeated half-inch-to12-inch values under length, height and mounting-hole diameter. The range cannot provide measured geometry or prove a hole feature.

Accept the complete service configuration

Low Pressure and Not Rated leave numerical duty unconfirmed. State actual fluid, pressure, temperature, cycling, loads and corrosion environment. Obtain system approval after material reconciliation, including pipe/wall compatibility, joining, alignment and inspection. Agree marking, required records, individual-size availability and quotation scope.
