Carbon Steel ASME B16.9 A234 WPB Sch40 Butt-Weld Straight/Reducing Tee Enquiry
Pour l’approvisionnement industriel
Préparez une RFQ plus claire
Indiquez les éléments ci-dessous afin que RELIA comprenne la pièce et discute avec vous de la prochaine étape.
- Plan, échantillon ou norme de référence
- Nuance du matériau et procédé préféré
- Dimensions, tolérances et finition de surface
- Application, quantité cible et destination
Délais de production, emballage et conditions d’expédition sont confirmés pour chaque projet après accord sur les spécifications et conditions commerciales.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
model numbertee 6046TechnicCasting
-
Connectivitymale femaleshapeEqual
-
head codeRoundOverall Length4 in
-
Height2Surface TreatmentPainting
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.25 inPipe FeaturesFlexible, Corrosion-resistant, Chemical Resistant
-
Pipe ClassNot RatedApplicationpetrochemical industry, Shipbuilding, Construction Engineering, Power Industry
-
Thread TypesNPT
This pipe tee page supports enquiries for a Schedule 40 carbon steel butt-weld configuration with an ASTM A234 WPB requirement. Start with the wall and diameter needed at each connection. The appropriate tee depends on the complete run and branch arrangement, the selected material grade and the applicable dimensional specification.
Specify the wall at every tee end
Give the outside diameter and required wall thickness for both run ends and the branch. Identify which dimensions represent nominal pipe sizes and which are actual measurements. State whether the branch must be equal or reduced, and show its position on the piping drawing. A single size selection does not describe the full three-ended fitting or establish that every end has the required wall.
Define the Sch40 and WPB requirements together
For the carbon steel configuration, state the required ASTM A234 WPB material specification and the applicable ASME B16.9 edition. Ask for confirmation that the requested Schedule 40 dimensions and any seamless-construction requirement apply to that same tee. Stainless Steel and Alloy alternatives require their own exact grades; their presence as material choices does not make them WPB equivalents.
Check the connection and service conditions
Identify the connection form and preparation at each intended welded end. Provide the mating pipe dimensions, design pressure, temperature and service medium so that fit and suitability can be assessed for the selected configuration. A schedule designation describes a dimensional requirement and does not by itself establish pressure capacity or chemical resistance. Before choosing the tee, obtain the dimensional drawing and material, construction and service qualification relevant to that exact request.
Informations techniques pour chaque demande produit
Préparez le besoin avant la confirmation finale du produit.
La page produit est un point de départ. Plans, échantillons, interfaces, matières, quantités et réception sont examinés avant confirmation du stock ou de la fabrication.
Discutez de ce produit dans le contexte de votre projet.
Partagez plan, échantillon, référence, quantité et application. Les points inconnus peuvent rester ouverts.
