SCH40 180° Carbon Steel Butt-Weld Elbow Enquiry
Pour l’approvisionnement industriel
Préparez une RFQ plus claire
Indiquez les éléments ci-dessous afin que RELIA comprenne la pièce et discute avec vous de la prochaine étape.
- Plan, échantillon ou norme de référence
- Nuance du matériau et procédé préféré
- Dimensions, tolérances et finition de surface
- Application, quantité cible et destination
Délais de production, emballage et conditions d’expédition sont confirmés pour chaque projet après accord sur les spécifications et conditions commerciales.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.25 in
-
Pipe Class1000SizeCustomized Size
-
Product nameElbow
A SCH40 carbon-steel butt-weld elbow for a requested 180-degree return needs a defined layout before selection. The title establishes the enquiry direction, while the size and material choices require a drawing that identifies the actual fitting. Curved fittings in the photographs do not establish the same return angle or dimensions for every option.
Set the return spacing and installation envelope
Show the required centreline radius, distance between the two end centres, overall height and clearances on the selected drawing. Check these dimensions against the adjoining parallel pipe runs and reserve access for welding and inspection. Confirm equal-end nominal size, outside diameter, actual wall and weld preparation at both ends. Explain what each millimetre label measures. The Hexagon and mounting-hole fields cannot replace a measured elbow layout.
Link SCH40 to a defined size and material
SCH40 must correspond to the chosen nominal size and actual wall record; it does not identify a fixed thickness across the listed sizes. Select carbon steel for the title requirement and request the exact material specification and grade. Stainless Steel and Alloy alternatives need their own material assignments. Agree applicable material and dimensional standards and editions, since the source supplies no standard number. Obtain traceable production and inspection evidence before accepting Forged as the actual manufacturing route.
Define coating and welded-return acceptance
Specify surface preparation, coating coverage and required weld-end condition rather than relying on Painting alone. Provide fluid, pressure, temperature, corrosion conditions and mating-pipe specifications for assessment of the complete joint. Pipe Class 1000 alone does not establish allowable duty. All Size and Customized Size do not prove arbitrary size capability, stock or availability. Base acceptance on the selected return drawing, size-linked wall, material records and agreed joining and inspection requirements.
Informations techniques pour chaque demande produit
Préparez le besoin avant la confirmation finale du produit.
La page produit est un point de départ. Plans, échantillons, interfaces, matières, quantités et réception sont examinés avant confirmation du stock ou de la fabrication.
Discutez de ce produit dans le contexte de votre projet.
Partagez plan, échantillon, référence, quantité et application. Les points inconnus peuvent rester ouverts.
