A234 90-Degree Steel Pipe Elbow Material Enquiries
Pour l’approvisionnement industriel
Préparez une RFQ plus claire
Indiquez les éléments ci-dessous afin que RELIA comprenne la pièce et discute avec vous de la prochaine étape.
- Plan, échantillon ou norme de référence
- Nuance du matériau et procédé préféré
- Dimensions, tolérances et finition de surface
- Application, quantité cible et destination
Délais de production, emballage et conditions d’expédition sont confirmés pour chaque projet après accord sur les spécifications et conditions commerciales.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
model number0354TechnicForged
-
ConnectivityWeldingshapeEqual
-
head codeHexagonOverall Length4 in
-
Height2Surface TreatmentPainting
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.25 inPipe FeaturesFlexible, Corrosion-resistant, Chemical Resistant
-
Pipe ClassNot RatedApplicationConstruction Engineering
-
Thread TypesGSizeCustomized Size
-
Product nameElbow
A 90-degree steel elbow request should connect the pipe route with a precise material and end arrangement. This product has Stainless Steel, Alloy and Carbon Steel choices, so identify the intended material before confirming the grade and construction required for the turn.
Locate the ninety-degree turn on the piping drawing
Provide the required turn angle, centerline radius and end positions relative to the adjoining pipes. Include any envelope or clearance restriction around the elbow. Confirm those dimensions for the selected configuration rather than assuming that a general elbow photograph establishes the angle or radius. The route drawing should describe the actual space occupied by the turn as well as the nominal sizes of its ends.
Define welding and thread requirements at the correct ends
Specify how each pipe interface must connect, with the relevant wall thickness and end preparation. If a G-thread requirement applies, identify the end and give its complete thread designation for confirmation. A welding label and a thread name do not define a complete connection pair by themselves. Keep the two end specifications together so the proposed elbow can be reviewed against both mating pipe interfaces.
Confirm A234 and construction for the chosen steel
State the required material specification and grade explicitly, including any A234 or seamless-construction requirement that needs confirmation. Obtain the applicable service rating for the selected material, wall and geometry, with the medium and design conditions included in the enquiry. A low-pressure or resistance descriptor does not establish a tested operating limit. Request the relevant material and construction documentation for that same elbow before accepting the proposed turn for service.
Informations techniques pour chaque demande produit
Préparez le besoin avant la confirmation finale du produit.
La page produit est un point de départ. Plans, échantillons, interfaces, matières, quantités et réception sont examinés avant confirmation du stock ou de la fabrication.
Discutez de ce produit dans le contexte de votre projet.
Partagez plan, échantillon, référence, quantité et application. Les points inconnus peuvent rester ouverts.
