A105 Carbon Steel Welded Tee for Water Treatment
Für industrielle Beschaffung
Eine klare RFQ vorbereiten
Mit den folgenden Angaben kann RELIA das Bauteil verstehen und den nächsten Schritt mit Ihnen besprechen.
- Zeichnung, Muster oder Referenznorm
- Werkstoffgüte und bevorzugtes Verfahren
- Abmessungen, Toleranzen und Oberfläche
- Anwendung, Zielmenge und Bestimmungsort
Fertigungszeit, Verpackung und Versandbedingungen werden nach Abstimmung von Spezifikationen und Handelskonditionen projektbezogen bestätigt.
-
warranty1 Yearcustomized supportOEM
-
TechnicFORGEDConnectivityWelding
-
shapeEqualhead codeHexagon
-
Overall LengthCustomized SizeHeightCustomized Size
-
Surface TreatmentPaintingPressureHigh Pressure
-
System of MeasurementMetricMounting hole diameterCustomized Size
-
Pipe FeaturesOtherPipe ClassOther
-
ApplicationOtherThread TypesCustomized Size
This carbon steel welded tee listing targets water treatment plants and includes A105, ANSI B16.5 and Class 150 references. The original image supports tee forms, while the selectable type reads Reducer. Confirm the exact fitting and approved drawing before accepting a material package or standard-based configuration.
Clarify B16.5 and class applicability
Identify which actual component or mating interface the B16.5 reference is intended to cover. Do not automatically apply a flange-standard title reference to the tee body. Request the fitting specification, applicable edition, component scope and conformity records required by the water treatment project.
Class 150 does not directly state allowable working pressure across the operating temperature range. The High Pressure and Other class table entries also leave numerical limits unspecified. Confirm the actual rating basis with the selected material, component and joint requirements rather than treating the class wording as a pressure certificate.
Verify material and ordered tee geometry
Obtain supplied grade, condition, traceability and material inspection documentation. The A105 title and a234wpb option do not establish one certified material package. Request production evidence supporting Forged and clarify the Welded reference against the actual connection and component construction for the selected order.
Specify run and branch sizes, bore, diameters, wall, center-to-end and welding end dimensions with tolerances. Confirm Equal geometry and the selected option mapping. Hexagon, Customized Size and Metric entries provide no measured values. Define Painting coverage, surface acceptance and coating inspection requirements separately from the standard and material references.
Set water treatment service acceptance
Provide water composition, treatment chemicals, contaminants, pressure, temperature, cycles, transients and loads. Assess the confirmed material, geometry, joint and surface package for those conditions, including any required water-contact approval. Agree material, dimensional and end inspections, coating records, marking, preservation and delivery against the plant requirements before release.
Technische Angaben für jede Produktanfrage
Anforderung vor der endgültigen Produktbestätigung vorbereiten.
Die Produktseite ist der Ausgangspunkt. Zeichnungen, Muster, Schnittstellen, Werkstoffe, Mengen und Abnahme werden vor Lagerzuordnung oder Sonderfertigung geprüft.
Dieses Produkt im Projektkontext besprechen.
Teilen Sie Zeichnung, Muster, Referenz, Zielmenge und Anwendung mit. Offene Punkte können in der Prüfung bleiben.
