Forged Carbon Steel 45-Degree Butt-Weld Elbow

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This forged carbon steel 45-degree butt-weld elbow is listed for construction applications with a B16.9 reference. The actual variant provides a half-inch to 12-inch nominal range. Select the individual size and complete drawing before requesting acceptance for a particular change in pipe direction.

Specify the actual 45-degree bend and mating pipe

Define the nominal sizing convention, radius, wall thickness or schedule and dimensional tolerances. Check the matching pipe dimensions and required installation envelope for the ordered size. No long-radius, seamless or specific wall schedule is supplied by this product record.

Length, height and hole entries repeat the range rather than describe the finished elbow. Request individual measurements on the drawing and explain the Hexagon head code. The angle identified by the title does not resolve those remaining dimensional requirements.

Confirm forged material and butt-weld end preparation

Obtain the complete selected carbon steel designation and condition, governing material document and edition, certificates and traceability. Define the B16.9 document and actual conformity scope for the component. Confirm the forging route and associated inspection records rather than treating a standard reference as completed certification.

Resolve the butt-weld title and NPT table entry with a schedule for each connection. Include preparation, full thread details where applicable, mating parts, sealing and joint examination. Agree measurable criteria for the smooth surface and the handling and protection needed through delivery.

Establish the intended construction duty and testing

Record actual medium composition, pressure and temperature limits, cycles, external exposure and mechanical loads. The Low Pressure and Not Rated fields give no numerical acceptance basis for this selected elbow. Verify corrosion suitability for that environment and obtain material, joint and rating evidence. Agree dimensional examination and testing requirements with the resolved supply specification before project approval.
