Painted Carbon Steel Butt-Weld Tee for Oil and Gas
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
warranty1 Yearcustomized supportOEM
-
TechnicFORGEDConnectivityWelding
-
shapeEqualhead codeHexagon
-
Overall LengthCustomized SizeHeightCustomized Size
-
Surface TreatmentPaintingPressureHigh Pressure
-
System of MeasurementMetricMounting hole diameterCustomized Size
-
Pipe FeaturesOtherPipe ClassOther
-
ApplicationOtherThread TypesCustomized Size
This painted carbon steel butt-weld tee listing is intended for oil and gas pipelines with ASME B16.9 and seamless references. The original image supports a tee form, while the selectable type reads Reducer. Confirm the ordered component and actual branch arrangement before relying on the Equal description.
Approve run and branch geometry together
The title and table say Equal, but the reviewed image shows a branch that appears smaller than the run. Appearance does not establish a reduction ratio or measured size. Request the actual run and branch drawing, with nominal sizes, diameters, bore, wall and center-to-end dimensions.
Confirm how this configuration maps to the selected option and define butt-welding end preparation, mating-pipe details and tolerances. Hexagon, Customized Size and Metric entries do not supply the missing measurements. Agree explicit units and dimensional inspection criteria for the selected fitting rather than using a generic range as a drawing.
Check ASME scope and production documentation
Identify the applicable ASME B16.9 edition, component coverage and project acceptance requirements. Obtain the actual manufacturing and inspection records supporting Forged and Seamless. A standard reference or construction word in the title does not prove conformity or document the production route of the supplied tee.
Request material grade, condition and traceability records; Carbon Steel and a234wpb options are not certificates. Specify the Painting treatment, covered surfaces, surface acceptance and coating inspections. Confirm handling and preservation requirements without inferring coating composition or corrosion performance from the dark appearance in the image.
Define the oil and gas pipeline envelope
Provide medium composition, contaminants, pressure, temperature, cycles, transients and external loads. High Pressure and Other class leave numerical limits unspecified. Assess the confirmed material, branch geometry, joint and surface package against the actual duty, then agree end inspections, documentation, marking, protection and delivery before release.
每个产品询价都需要的技术信息
在最终确认产品前先整理需求。
产品页只是起点。在确认库存匹配或定制生产前，我们会评审图纸、样品、接口、材料、数量及验收要求。
结合您的项目场景讨论该产品。
提供现有图纸、样品、参考件、目标数量及应用信息。尚不确定的项目可留待评审。
