SCH40/80/120 Weld-End Tee Enquiry | Stainless & A234 WPB Carbon Steel
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentSmoothMounting hole diameter0.25 in
-
Pipe Class125SizeCustomized Size
-
Product nameElbow
This weld-end tee enquiry lists SCH40, SCH80 and SCH120 with stainless-steel alternatives and A234 WPB carbon-steel references. Actual types include both TEE and Elbow. Choose the intended fitting first, then assign one schedule and exact material so the selected drawing and records describe the same component.
Select the type before defining branch or bend geometry
For TEE, label both run openings and the branch with nominal sizes, outside diameters, actual walls, branch orientation and centre-to-end dimensions. For Elbow, request the required angle, centreline radius and dimensions of its two ends. The tee photographs cannot define the separate elbow geometry. Explain what each millimetre label measures and whether equal ends are required for the chosen type. Check the branch or bend layout against adjoining pipes, nearby supports and access for joining and inspection.
Assign one schedule and traceable material package
Select SCH40, SCH80 or SCH120 explicitly and connect it to the chosen nominal size and actual wall record. The three labels do not establish one thickness or availability across every option. Choose Carbon Steel for the A234 WPB requirement and obtain the complete material specification, edition and traceable grade records. Stainless Steel and Alloy choices need separate exact assignments. No dimensional standard number is supplied, so agree applicable dimensions, tolerances and inspection for the selected type.
Define weld-end, surface and service acceptance
Match weld preparation and actual wall to every mating pipe. Verify Forged through production and inspection evidence, and define measurable surface-finish requirements beyond Smooth. The dark tee photographs do not qualify schedule wall, grade or manufacture. Provide fluid, pressure, temperature and corrosion conditions with the joining and inspection procedure for complete-joint assessment. Pipe Class 125 does not itself establish allowable service. Confirm the offered dimensional range and availability separately from Customized Size, then link acceptance to the selected type, schedule and material records.
每个产品询价都需要的技术信息
在最终确认产品前先整理需求。
产品页只是起点。在确认库存匹配或定制生产前，我们会评审图纸、样品、接口、材料、数量及验收要求。
结合您的项目场景讨论该产品。
提供现有图纸、样品、参考件、目标数量及应用信息。尚不确定的项目可留待评审。
