90° Stainless Steel Pipe Fitting Elbow Enquiry
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.25 in
-
Pipe Class125SizeCustomized Size
-
Product nameElbow
This stainless elbow enquiry requests a ninety-degree change of pipe direction. The actual variants identify Elbow with broad material and millimetre size choices, but do not assign a bend radius, exact grade or wall. Use a selected drawing to define how the bend will fit your two adjoining pipes.
Check radius and clearance around the direction change
Confirm the requested angle with its tolerance, centreline radius and centre-to-end dimensions. Record the orientation and available installation space before selecting the bend. The photographs show several silver curved examples without establishing actual dimensions or material. Do not classify the selected elbow as short-radius or long-radius from those images; that choice needs the documented geometry.
Translate the size choice into both end measurements
Explain the nominal-size convention behind the millimetre menu labels, then verify each outside diameter and wall with the mating pipe data. Confirm what Equal means for the selected drawing. Hexagon, the mounting-hole value and Customized Size do not provide complete bend dimensions or a supplied capacity range. Establish the applicable dimensional requirement and wall designation; no schedule is stated here.
Define the stainless material and actual welded joint
Choose one exact stainless grade with complete specifications and traceability; the page does not identify 304 or 316. Alloy and Carbon Steel alternatives need their own material and joining assessment. Define Welding through the actual end detail, preparation, alignment and inspection requirements, without assuming a particular weld-end design. Verify Forged through production records and clarify Painting and joint-zone condition. Establish Pipe Class 125's standard, unit and material/temperature basis, then evaluate fluid, pressure, temperature, corrosion and mechanical loads across the bend and both completed joints.
每个产品询价都需要的技术信息
在最终确认产品前先整理需求。
产品页只是起点。在确认库存匹配或定制生产前，我们会评审图纸、样品、接口、材料、数量及验收要求。
结合您的项目场景讨论该产品。
提供现有图纸、样品、参考件、目标数量及应用信息。尚不确定的项目可留待评审。
