SS/Carbon Steel Hex Nipple DN6 DN80, 304/316 A234 Pipe Fitting Enquiry
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.2 in
-
Pipe Class150SizeCustomized Size
-
Product nameElbow
This DN6/DN80 304/316 A234 hex-nipple enquiry needs a selected fitting drawing and material specification. Define both connecting ends and the required central body or wrenching feature before ordering. Title references alone do not establish a supplied grade, size range or complete configuration.
Select the actual size and material
Fifteen actual Nipple variants pair each 10 mm, 12 mm, 14 mm, 50 mm and 30 mm label with Stainless Steel, Alloy or Carbon Steel. Choose the required combination and define its nominal or measured size meaning. DN6 and DN80 naming does not establish a continuous available range or an automatic mapping to these labels.
Assign 304/316 and A234 references to the intended component and material designation, edition, grade and product condition. Request inspection traceability and applicable forged-production evidence. Generic material alternatives are not certified grades or interchangeable specifications.
Draw both ends and wrench clearance
Specify overall length, bore, wall, end dimensions, relevant engagement, central wrenching geometry and tolerances. The inspected images show externally threaded open-ended tubes; they do not clearly establish a distinct central hexagonal section or certify the supplied thread standard. Agree the requested hex feature and installation tool access on the drawing.
Define each end's connection, sealing and mating-interface requirements, including any welding arrangement relevant to the selected component. Equal shape wording does not supply complete geometry. Customized dimensions need approval, and the separate 0.2-inch mounting-hole entry cannot define nominal size or thread designation.
Set finish and operating acceptance
Agree painting scope, preparation and functional-surface exclusions without assuming coating performance. Class 150 requires its governing standard and material-temperature basis. Provide the medium, pressure, temperature, cycling and imposed loads, then confirm installation, mating-part compatibility, inspection, drawing approval, requested OEM, ODM or OBM scope, and the stated one-year warranty terms.
每个产品询价都需要的技术信息
在最终确认产品前先整理需求。
产品页只是起点。在确认库存匹配或定制生产前，我们会评审图纸、样品、接口、材料、数量及验收要求。
结合您的项目场景讨论该产品。
提供现有图纸、样品、参考件、目标数量及应用信息。尚不确定的项目可留待评审。
