DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint

DIN PN10 Flange Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
链接复制成功

工业采购项目

准备更清晰的 RFQ

请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。

  • 图纸、样品或参考标准
  • 材料牌号和首选工艺
  • 尺寸、公差和表面处理
  • 应用、目标数量和目的地
提交项目资料 电子邮箱 WhatsApp Telegram

生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
商品描述
  • warranty
    1 year
    customized support
    OEM, ODM
  • model number
    N-RJ
    Technic
    Forged
  • Connectivity
    Flange
    shape
    Equal
  • head code
    Round
    Overall Length
    According to pipeline requirements
  • Height
    According to pipeline requirements
    Surface Treatment
    Cleaning Supplies
  • Pressure
    Low Pressure
    System of Measurement
    inch
  • Mounting hole diameter
    According to pipeline requirements
    Pipe Features
    Flexible, Corrosion-resistant, Chemical Resistant
  • Pipe Class
    Not Rated
    Product name
    Double Sphere Dual EPDM Corrugated Compensator Rubber Expansion Joint
  • Working Pressure
    6-40bars(PN6-PN40)
    Working Temperature
    -15℃-80℃(-30℃-150℃)
  • Test pressure
    1.5 times of working pressure
    Explosion pressure
    2 times of working pressure
  • Applicable media
    Air,water,sewage,acid,oil,etc.
    Nominal diameter
    DN40-DN1200
  • Flange material
    Carbon steel galvanized,Stainless steel etc.
    Rubber material
    NR,EPDM,NBR etc.
  • Flange Standard
    DIN,ANSI,JIS etc.
