Lateral Tee for Chemical Industry Piping
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
warranty1 Yearcustomized supportOEM
-
TechnicFORGEDConnectivityWelding
-
shapeEqualhead codeHexagon
-
Overall LengthCustomized SizeHeightCustomized Size
-
Surface TreatmentPaintingPressureHigh Pressure
-
System of MeasurementMetricMounting hole diameterCustomized Size
-
Pipe FeaturesOtherPipe ClassOther
-
ApplicationOtherThread TypesCustomized Size
This fitting listing targets chemical industry piping with ASTM A403, stainless grades and a 45-degree lateral tee reference. The selectable variants instead use Reducer with Carbon Steel or a234wpb. Confirm the actual fitting family, material and branch drawing before adopting the title as a supplied specification.
Resolve the selected fitting and stainless grade
The original photograph shows a three-opening fitting with an angled branch, supporting a tee enquiry but not a measured angle. Map the Reducer-labelled options to an approved drawing and the actual supplied fitting. Resolve the stainless title against both carbon material choices through traceable specification, grade, condition and inspection records.
Identify the ASTM A403 edition, product coverage and conformity requirements after the material is confirmed. WP304 and WP316L wording does not select one supplied grade or establish interchangeable chemical compatibility. Verify the actual manufacturing route and finish against FORGED and Painting entries rather than inferring them from metallic appearance.
Specify lateral geometry and welded-end requirements
The half-inch to 110-inch option is a range, not the selected run and branch sizes. State actual diameters, wall, branch angle and centre-to-end dimensions. Reconcile the lateral title with Equal table wording on the drawing; the photograph cannot verify a 45-degree angle or equal end diameters.
Confirm the Welding connection, end preparation, bevels and mating-pipe geometry. Customized length and height require ordered values. Hexagon head and mounting-hole or thread fields do not establish a flange, threaded connection or actual hole layout. Define any relevant features explicitly instead of transferring generic table labels to the selected part.
Set chemical duty and traceable branch-fitting acceptance
Provide medium composition, contaminants, pressure, temperature, cycles, loads and joint requirements. High Pressure and Other class entries do not supply a numerical rating for this fitting. Agree material, dimensional, end, surface and required project tests with criteria and records. Approve the documented fitting against the actual chemical system before accepting corrosion or operating suitability.
每个产品询价都需要的技术信息
在最终确认产品前先整理需求。
产品页只是起点。在确认库存匹配或定制生产前，我们会评审图纸、样品、接口、材料、数量及验收要求。
结合您的项目场景讨论该产品。
提供现有图纸、样品、参考件、目标数量及应用信息。尚不确定的项目可留待评审。
