Grade 6 A333 ERW Pipe for Low-Temperature Enquiries
工业采购项目
准备更清晰的 RFQ
请提供以下信息，帮助 RELIA 理解零件要求并与您确认下一步。
- 图纸、样品或参考标准
- 材料牌号和首选工艺
- 尺寸、公差和表面处理
- 应用、目标数量和目的地
生产周期、包装和运输条款将在规格与贸易条件确认后按项目确定。
-
InvoicingBy Actual WeightOiled or Non-oiledNon-oiled
-
Section ShapeRoundSurface TreatmentCold Rolled
-
Tolerance±1%Alloy Or NotNon-Alloy
-
ApplicationFluid Pipe, Drill Pipe, Hydraulic Pipe, Gas Pipe, Oil PipeCertificateAPI , ISO 9001
-
Delivery Time8 ~ 14 daysGradecarbon steel
-
Outer Diameter219 - 1066 mmSpecial PipeAPI Pipe, Other, EMT Pipe, Thick Wall Pipe
-
StandardASTMTechniqueERW
This Grade 6 A333 ERW pipe is listed for low-temperature pipeline enquiries with cryogenic wording and a B36.10 dimensional reference. The source identifies carbon steel and ERW manufacture. Confirm the selected material condition and actual service temperature before treating the listing as acceptance for a cryogenic system.
Establish the required temperature and material evidence
Provide the intended fluid and full operating temperature range, including the project minimum, with pressure and cycling requirements. Low Temperature and Cryogenic in a title supply no numerical limit. They do not demonstrate suitability for every low-temperature medium or operating condition.
Request the applicable A333 edition, full Grade 6 condition and selected manufacturing scope. Obtain traceable chemistry, property and inspection records, including the low-temperature tests and acceptance evidence required for the proposed supply. The ERW weld and intended joints need assessment within that documented project basis.
Select dimensions against the relevant reference
Outside diameter is recorded as 219–1066 mm. The two variants pair a 6–20 mm thickness range with 12 m or 6 m length. Specify one actual diameter, wall, length and end configuration, then confirm the relevant B36.10 edition and dimensional applicability.
A wall range does not identify a schedule or establish every available combination. Define the measurement controlled by ±1% and agree dimensional, geometry and weld inspection requirements. Check the cold-rolled, round and non-oiled supply condition; no additional protective coating is established by those entries.
Complete the pipeline acceptance and certificate review
Include mechanical loads, joint requirements and project rating evidence with the operating envelope. Agree selected tests and traceability before acceptance. API and ISO 9001 labels require actual certificate scope and validity checks. EMT wording does not establish conduit qualification or alter the evidence needed for the low-temperature pipeline duty.
