45 Degree Forged Carbon Steel Elbow for Construction

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This 45-degree forged carbon steel elbow enquiry concerns construction applications. The title refers to 24 inches, while the actual option lists a half-inch-to-12-inch range. Confirm the size that can be supplied before procurement; the existing option does not separately select the title dimension.

Resolve the 24-inch reference and elbow geometry

Request supplier confirmation and an approved drawing for the intended size. Preserve the actual range pending clarification rather than assuming it includes 24 inches. Obtain outside diameters, bores, wall thickness, bend angle, radius, center-to-end dimensions and tolerances for the selected elbow.

The title provides a 45-degree reference, but no long/short radius or wall schedule is recorded. ASME wording lacks an exact document number. Agree the governing dimensional specification explicitly without adding an unrecorded standard or using the title as certification of the supplied geometry.

Confirm welding or NPT ends and actual measurements

The table records Welding and NPT in separate fields. Obtain end details, matching pipe and joining requirements to reconcile them. Length, height and mounting-hole entries repeat the broad size range; request measured values and clarify whether a hole feature exists. Resolve Hexagon against the drawing.

Ask for the full carbon steel designation, condition, traceability, material certificates and evidence supporting forged manufacture. No WPB or seamless designation is supplied here. Black and smooth wording do not identify a coating system; agree the actual surface treatment and inspection without assuming corrosion suitability.

Set construction duty after the selection is complete

Low Pressure and Not Rated leave numerical limits unconfirmed. Provide medium, pressure, temperature, exposure, cycling and loads, then obtain compatibility acceptance. Agree joining, alignment, support, inspection, marking, material/process/dimensional records, warranty terms and quotation scope for the selected component.
