F316L Stainless Steel 45-Degree Socket-Weld Elbow

• warranty

  1 Year
  customized support

  OEM
• Technic

  Forged
  Connectivity

  Welding
• shape

  Equal
  head code

  Hexagon
• Overall Length

  2.8 in
  Height

  1
• Surface Treatment

  Smooth
  Pressure

  Low Pressure
• System of Measurement

  inch
  Mounting hole diameter

  0.25 in
• Pipe Features

  Corrosion-resistant, Chemical Resistant, Uv Resistant
  Pipe Class

  150
• Application

  petrochemical industry, Metallurgical Industry, home appliance installation, building water supply and drainage
  Thread Types

  NPT

This forged stainless steel elbow is listed with F316L, a 45-degree angle and socket-welding wording. The title names 2 inch, while the only variant is 15 mm. Resolve the actual ordered size before selecting the end arrangement or treating the component as ready for a particular service.

Resolve the inch and metric size references

Provide a drawing identifying nominal ends, dimensional convention, bend angle, radius, wall and tolerances. The 2-inch and 15 mm labels cannot be assumed equivalent. Clarify the Equal entry and confirm actual socket dimensions and installation envelope for the selected fitting.

Allocate the listed 2.8 in length and 0.25 in hole to real features. The height value is 1 without a unit, so obtain its unit and dimensional role. Confirm size availability and measured acceptance criteria instead of deriving a drawing from isolated table values.

Specify F316L supply and socket-weld interfaces

Request the full selected material specification, edition, condition and traceability, with forging and inspection records. The F316L title reference identifies a material enquiry but does not establish certification. Agree the required material package for the actual medium and component.

Resolve socket welding and NPT through an end schedule. Define socket preparation, mating dimensions, welding acceptance and any applicable thread designation, sealing and examination. Do not assume the connection labels are interchangeable. Set measurable Smooth finish requirements and delivery protection.

Confirm the pressure basis and application evidence

Identify the governing basis for Class 150 at the selected material and temperature; the number is not a stand-alone operating pressure. Provide medium, numerical duty, cycling, corrosion and exposure conditions. Obtain relevant chemical, corrosion or UV evidence and agree material/joint acceptance for the intended application with the drawing, supply and test documents.
