Class 150 Polished Stainless Steel Blind Flange
Per l’approvvigionamento industriale
Prepara una RFQ più chiara
Includi i dati seguenti per aiutare RELIA a comprendere il componente e definire il passo successivo.
- Disegno, campione o norma di riferimento
- Grado materiale e processo preferito
- Dimensioni, tolleranze e finitura superficiale
- Applicazione, quantità obiettivo e destinazione
Tempi di produzione, imballaggio e condizioni di spedizione vengono confermati per ogni progetto dopo l’accordo su specifiche e condizioni commerciali.
-
Surface TreatmentPolishedApplicationIndustrial Equipment
-
Bolt Hole Diameter1/2"Bolt Hole Quantity4
A Class 150 polished stainless steel blind flange is the focus of this industrial-equipment listing. Stainless Steel/Blind Flange is an actual selectable combination. Confirm the chosen material and closure configuration before carrying the title’s forged, A105 or high-pressure references into an order.
Clarify the stainless selection and A105 reference
The catalogue contains thirty-six combinations covering four materials and nine flange types. Carbon Steel/Blind Flange is also selectable. Ask which exact material specification applies to the selected item; the combined title does not allocate A105 to every stainless choice.
Request full grade, condition, traceability and accepted material certificates, plus manufacturing evidence for forged construction. Specify which surfaces require polishing and how finish is inspected. Neither a stainless option nor a polished surface establishes corrosion, chemical or hygienic suitability for the proposed service.
Confirm Class 150 against the individual drawing
Agree the governing document, edition and applicable size/material provisions for the Class 150 reference. Obtain approved pressure-temperature limits rather than treating the class number as working pressure. The shared half-inch-to120-inch label requires confirmation of individual nominal size and actual supply.
Review outside diameter, thickness, facing geometry/finish, bolt circle, hole count, hole diameter and tolerances. The table lists four half-inch holes; allocate those entries to the selected drawing instead of assuming identical drilling across all sizes and materials.
Approve the complete blind-flange joint
Define medium, pressure, temperature, cycling, loads and compatibility; High Pressure alone is qualitative. Confirm mating flange, gasket, bolting, alignment and installation inspection for the completed joint. Agree material, manufacturing, dimensional and class records, marking, included parts and quotation scope before procurement.
Informazioni tecniche per ogni richiesta prodotto
Prepara i requisiti prima della conferma finale del prodotto.
La pagina prodotto è un punto di partenza. Disegni, campioni, interfacce, materiali, quantità e accettazione vengono verificati prima di confermare stock o produzione.
Valuta questo prodotto nel contesto del tuo progetto.
Condividi disegno, campione, riferimento, quantità e applicazione. I punti non definiti possono restare aperti.
