LF2 Carbon Steel Socket-Weld Flange for Low-Temperature Use
Per l’approvvigionamento industriale
Prepara una RFQ più chiara
Includi i dati seguenti per aiutare RELIA a comprendere il componente e definire il passo successivo.
- Disegno, campione o norma di riferimento
- Grado materiale e processo preferito
- Dimensioni, tolleranze e finitura superficiale
- Applicazione, quantità obiettivo e destinazione
Tempi di produzione, imballaggio e condizioni di spedizione vengono confermati per ogni progetto dopo l’accordo su specifiche e condizioni commerciali.
-
Surface TreatmentPolishedApplicationAgricultural Irrigation, Air Conditioning, Chemical Industry, Construction, Environmental Engineering, Fiber Optic Co MMunication, Food And Beverage, HVAC, Mining, nuclear power, Oil And Gas, paper industry, Pharmaceutical, Power Generation, Shipbuilding, Steel Industry, Textile Industry, Wastewater Treatment, water supply, Industrial Equipment
-
Bolt Hole Diameter1/2"Bolt Hole Quantity4
This LF2 carbon steel socket-weld flange enquiry follows the A350, B16.5 and low-temperature title references. The title includes forged, polished and Class 300–1500 wording. Confirm the selected carbon socket-weld configuration and actual temperature requirements before approving the material or component for service.
Specify the socket-weld configuration and individual drawing
The record has 36 variants across four materials and nine flange types. Alloy Steel, Aluminum, Carbon Steel and Stainless Steel pair with integral, weld neck, slip-on, socket-weld, lap-joint, threaded, blind, orifice and spectacle blind types. LF2 and socket-weld title details concern the matching subset.
Choose one nominal size from the half-inch to 120-inch range and identify the required class. Request socket, bore, mating pipe dimensions, wall, outside dimensions, face and tolerances. Allocate the listed four half-inch bolt holes to the selected drawing; the bolt reference does not specify nominal flange size.
Verify LF2 supply and the claimed conformity package
Obtain the complete material designation and condition, governing A350 and B16.5 documents and editions, actual component scope, forging evidence, certificates and traceability. The record does not select a further grade subdesignation. Request the exact ISO standard, certificate, scope and validity behind ISO Certified wording before asserting certification.
Define measurable polished-finish acceptance, connection preparation, mating interface, sealing, bolting and examination. Confirm the selected material/temperature rating basis and delivery protection. The class range does not establish every size/class combination or translate directly into operating pressure.
Qualify the actual low-temperature operating conditions
Specify minimum and maximum temperatures, medium composition, pressure, cycling, exposure and loads. Require material, toughness, joint and rating evidence for those conditions rather than relying on Low Temp alone. Agree the selected drawing, conformity and inspection/testing package; the broad industry list does not establish approval for every application.
Informazioni tecniche per ogni richiesta prodotto
Prepara i requisiti prima della conferma finale del prodotto.
La pagina prodotto è un punto di partenza. Disegni, campioni, interfacce, materiali, quantità e accettazione vengono verificati prima di confermare stock o produzione.
Valuta questo prodotto nel contesto del tuo progetto.
Condividi disegno, campione, riferimento, quantità e applicazione. I punti non definiti possono restare aperti.
