WPB Forged Carbon Steel 90-Degree Long-Radius Elbow

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This WPB forged carbon steel 90-degree long-radius elbow is listed for construction with butt-weld and A234 references. Its single nominal size option is a half-inch to 12-inch range. Confirm the required size and full drawing before choosing the component for a particular pipe route.

Define the individual bend within the listed range

Record the sizing convention, actual long radius, wall thickness or schedule and dimensional tolerances for the 90-degree elbow. Identify the mating pipe dimensions and required envelope. The title supplies the bend description, while the range does not establish each finished dimension or selected wall.

Request actual length, height and hole measurements because the table repeats the range in those fields. Explain the Hexagon head code and its purpose on the drawing. Do not import seamless manufacture, a wall schedule or an additional dimensional standard from a similar elbow.

Verify forged WPB material and allocate the ends

Obtain the complete selected material designation and condition, material certification and traceability. Specify the governing A234 document and edition with the conformity scope for the ordered component. Confirm the forged route and the associated production inspection records before approving the material package.

Clarify the butt-weld title and NPT table entry through a schedule for each end. Agree preparation, any relevant full thread specification, mating interfaces, sealing and examination requirements. Establish measurable acceptance for the smooth surface without assuming a particular coating, and define delivery protection.

Set construction operating and corrosion criteria

Describe medium composition, pressure and temperature limits, cyclic loading, environmental exposure and mechanical loads. Low Pressure and Not Rated do not establish numerical acceptance for the selected size and wall. Require corrosion evidence relevant to the actual environment and obtain the material, joint and rating basis. Agree dimensional checks and testing requirements in the final supply documents.
