B16.5 A105 Class 300 Carbon Steel Blind Flange Enquiry
Per l’approvvigionamento industriale
Prepara una RFQ più chiara
Includi i dati seguenti per aiutare RELIA a comprendere il componente e definire il passo successivo.
- Disegno, campione o norma di riferimento
- Grado materiale e processo preferito
- Dimensioni, tolleranze e finitura superficiale
- Applicazione, quantità obiettivo e destinazione
Tempi di produzione, imballaggio e condizioni di spedizione vengono confermati per ogni progetto dopo l’accordo su specifiche e condizioni commerciali.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentSmoothMounting hole diameter0.26 in
-
Pipe Class300SizeCustomized Size
-
Product nameElbow
This B16.5 A105 Class 300 carbon steel blind-flange enquiry needs confirmation of the offered closure. Actual variants say Flange, while both reviewed gallery images show central openings, one apparently threaded. Obtain the selected solid blind drawing and matching product evidence before treating the title as an actual closure specification.
Confirm the solid blind against the gallery and selection
Ask whether the offered item is a solid blind flange and how its product evidence maps to the selected variant. Do not silently relabel it as a bored or threaded flange from the photos. The broad flange family is supported despite the imported Elbow table name. Define closure thickness, outside diameter, bolt circle, hole count and hole diameter on the selected drawing. Explain each millimetre menu size rather than assuming a nominal size or hole measurement.
Qualify A105 and Class 300 for the selected flange
Choose Carbon Steel for this enquiry and request the complete A105 material specification, edition and traceable records. Stainless Steel and Alloy alternatives need separate materials. Agree the applicable B16.5 edition and selected dimensional, material and rating evidence. Class 300 is not a pressure value independent of material and temperature. Support Forged and the actual surface condition with production and inspection records.
Assess the mating face and complete closure joint
Specify the sealing face, finish, mating flange, gasket and bolting as a matched assembly. Clarify the Welding table entry through the actual installation drawing; it does not establish a weld connection for a blind closure. Generic Equal, Hexagon and mounting-hole fields cannot replace that drawing. Provide fluid, pressure, temperature, corrosion and end-closure loads for full joint assessment. Customized Size does not establish supplied dimensions; confirm solid closure before accepting the assembled boundary.
Informazioni tecniche per ogni richiesta prodotto
Prepara i requisiti prima della conferma finale del prodotto.
La pagina prodotto è un punto di partenza. Disegni, campioni, interfacce, materiali, quantità e accettazione vengono verificati prima di confermare stock o produzione.
Valuta questo prodotto nel contesto del tuo progetto.
Condividi disegno, campione, riferimento, quantità e applicazione. I punti non definiti possono restare aperti.
