ASME B16.11 Class 6000 Carbon Steel BW/SW/Threaded Branch Outlet Enquiry

• warranty

  1 year
  customized support

  OEM, ODM
• model number

  forged fitting 6201
  Technic

  Forged
• Connectivity

  Male/Female
  shape

  Equal/Reducing
• head code

  Hexagon/Round
  Overall Length

  4 in
• Height

  2
  Surface Treatment

  Smooth
• Pressure

  High Pressure
  System of Measurement

  inch
• Mounting hole diameter

  0.25 in
  Pipe Features

  Flexible, Corrosion-resistant, Chemical Resistant
• Pipe Class

  Not Rated
  Application

  Agricultural Irrigation, Automotive Repair, Heating Systems
• Thread Types

  NPT

This branch outlet page supports an enquiry with a specified butt-weld, socket-weld or threaded branch connection and any required ASME B16.11 or class 6000 conditions. Choose one outlet form before defining the configuration. The run-pipe attachment and the branch connection need separate dimensions and qualification for the intended service.

Select one branch connection form

State whether the branch connection must be butt welded, socket welded or threaded. Give the branch nominal size, actual diameter, wall and the preparation or thread specification needed for that interface. Different connection names should not be treated as one interchangeable fitting. Ask for a drawing of the selected outlet form so that the branch detail can be checked against the mating pipe.

Confirm the base against the run pipe

Provide the run-pipe outside diameter and wall separately from the branch size. Show the required attachment geometry and ask for confirmation that the outlet base contour matches the run pipe. A single selectable size does not establish the full run-and-branch relationship. Include any installation dimensions needed to position the outlet correctly on the piping drawing.

Qualify class and standard for the chosen outlet

State the exact Carbon Steel or Stainless Steel grade and required construction. Identify any ASME B16.11 and class 6000 requirement explicitly, then confirm its applicability to the selected outlet form. Naming a class does not establish high-pressure capability for every connection variant. Provide design pressure, temperature and the service medium, and request the relevant dimensional, material, construction and pressure-temperature evidence. Review those records with the run and branch drawing before accepting the outlet for service.
