DN15 JIS B2220 5K 4-Inch A182 F5 Polished Slip-On Plate Flange Enquiry

• warranty

  3 Years
  customized support

  OBM, ODM, OEM
• model number

  PPF-PH
  Technic

  Mould
• Connectivity

  Bolted
  shape

  Equal
• head code

  Round
  Overall Length

  1/8"-6"
• Height

  1/8"-6"
  Surface Treatment

  Polishing
• Pressure

  Low Pressure
  System of Measurement

  inch
• Mounting hole diameter

  1/8"-6"
  Pipe Features

  No additional Features
• Pipe Class

  150
  Application

  building water supply and drainage, fire protection systems, natural gas pipeline installation, natural gas & petroleum industry, natural gas transportation, water supply and drainage systems
• Thread Types

  NPT OR BSPT

This JIS B2220 5K slip-on plate flange enquiry includes DN15, four-inch and A182 F5 references. Define the intended component on an approved drawing before selecting its nominal size, material or rating. The bolted assembly needs a clear specification for both its pipe attachment and mating interface.

Assign the DN15 and four-inch dimensions

State which dimension each size reference describes instead of choosing one or assuming equivalence. Size None is not a selected nominal dimension. Specify the bore, outside diameter, thickness, facing, bolt circle, hole count, hole diameters and tolerances for the actual flange.

Show the required plate construction and slip-on arrangement on the assembly drawing. Generic Flange choices cannot certify those details, and repeated inch ranges for length, height and mounting-hole diameter do not complete the interface. Identify any backing or support components included in supply.

Agree the 5K scope and component material

Confirm the applicable JIS B2220 edition, selected type, nominal size, material and rating designation. Do not treat 5K and Class 150 as equivalent or combined ratings. Establish the accepted pressure-temperature basis rather than relying on low-pressure wording as an operating limit.

Request the supplied material specification, product condition and inspection traceability for each component. Polypropylene or PP choices need an accepted material designation and supply scope. A182 F5 naming alone cannot certify a PP part or establish the material of the entire joint.

Approve the slip-on assembly conditions

Define the pipe-side attachment separately from the bolted mating connection, including any NPT or BSPT feature. Agree finish and production requirements without inferring corrosion or sealing performance from polishing. Provide the medium, numerical duty, cycling and loads for the project. Review mating parts, gasket, fasteners, support and assembly requirements together, and confirm PPF-PH applicability, customization scope and three-year warranty terms in the quotation.
