PN16 Carbon Steel Lap Joint and Threaded Flange
Para sourcing industrial
Prepare uma RFQ mais clara
Inclua os dados abaixo para que a RELIA entenda a peça e alinhe o próximo passo com você.
- Desenho, amostra ou norma de referência
- Classe do material e processo preferido
- Dimensões, tolerâncias e acabamento superficial
- Aplicação, quantidade-alvo e destino
Prazo de produção, embalagem e condições de envio são confirmados por projeto após o acordo de especificações e termos comerciais.
-
Surface TreatmentPolishedApplicationIndustrial Equipment
-
Bolt Hole Diameter1/2"Bolt Hole Quantity4
This PN16 polished carbon steel flange listing includes separate lap-joint and threaded choices. Both configurations exist among thirty-six catalogue combinations. Select one form and confirm the supplied assembly before applying the title’s material, pressure designation or seamless wording to a purchase requirement.
Distinguish lap-joint scope from threaded construction
For a lap-joint enquiry, identify the actual companion end/connection components and mating arrangement, including which parts are supplied. For a threaded enquiry, specify thread standard, size, engagement, sealing and mating compatibility. The two type choices do not establish a hybrid flange.
Obtain full carbon steel designation, grade, condition, traceability and certificates for the selected item. Clarify the seamless reference with manufacturing records rather than assuming certification from the title. Other material/type options require their own approved specifications and included-parts scope.
Allocate PN16 and drilling to the selected configuration
Agree the governing document, edition and applicable size/material provisions for PN16. Obtain approved pressure-temperature limits; the designation alone does not certify actual operating duty. No exact dimensional standard is supplied here. Confirm individual nominal size and actual availability within the shared half-inch-to120-inch range.
Require outside diameter, thickness, bore/interface, facing geometry/finish, bolt circle and tolerances on a drawing. Allocate the table’s four half-inch holes to that configuration, checking actual count and diameter. They neither identify nominal flange size nor establish universal drilling. Define polished surfaces and inspection criteria.
Approve the complete equipment joint
State medium, pressure, temperature, cycling, loads and material/sealing compatibility. Polishing does not certify corrosion performance. Obtain complete joint approval covering mating flange, companion parts where relevant, gasket, fasteners, alignment and installation inspection. Agree marking, documents, individual supply and quotation scope.
Informações técnicas para cada consulta
Prepare os requisitos antes da confirmação final do produto.
A página é o ponto de partida. Desenhos, amostras, interfaces, materiais, quantidades e aceitação são avaliados antes de confirmar estoque ou produção.
Discuta este produto no contexto do seu projeto.
Compartilhe desenho, amostra, referência, quantidade e aplicação. Pontos desconhecidos podem ficar em aberto.
