Carbon Steel Pipe Fitting ThreadOlet Branch Outlet
Para sourcing industrial
Prepare uma RFQ mais clara
Inclua os dados abaixo para que a RELIA entenda a peça e alinhe o próximo passo com você.
- Desenho, amostra ou norma de referência
- Classe do material e processo preferido
- Dimensões, tolerâncias e acabamento superficial
- Aplicação, quantidade-alvo e destino
Prazo de produção, embalagem e condições de envio são confirmados por projeto após o acordo de especificações e termos comerciais.
-
warranty1 yearcustomized supportCustomized
-
model numberMSS SP 97 ANSI B16.11 ASME B16.9TechnicForged
-
ConnectivityWeldingshapeReducing
-
head codeRoundProduct Nameweldolet sockolet threadolet nipolet flangolet
-
Size1/8"-4"StandardMSS SP 97 ASME B16.9
-
Pressure2000lbs 3000lbs 6000lbsWall thicknesssch10--sch160 xxs customized
-
ProcessforgedMaterialcarbon steel stainless stee
-
Advantagesfaster delivery time customizedPayment TermsLC TT
-
PortHebei China
A forged branch outlet pipe fitting needs a clear relationship between the main run pipe and its branch. For this ThreadOlet enquiry, begin with the outlet form and the connection required at each side, then select the material family for the project.
Identify the branch end and run attachment
A threaded branch end and the attachment to the run pipe describe different parts of an outlet connection. State the required branch thread designation separately from the run attachment, and confirm the outlet form against a drawing before treating threaded and welding-end forms as alternatives.
The branch connection should be selected for the intended joint arrangement. A photograph can help discuss shape, but it cannot establish the thread standard, dimensional fit or qualification of the exact outlet requested.
Pair the run dimensions with the branch
An outlet enquiry needs the run pipe size as well as the branch size. Include pipe wall thickness and the required orientation so the attachment profile and branch arrangement can be checked together, rather than relying on a single size selection.
Stainless Steel, Alloy and Carbon Steel are separate material choices for this product. Specify the required grade, and confirm the applicable outlet standard and design conditions for the selected combination; a class label alone does not establish its working pressure at the intended temperature.
Make the outlet drawing the enquiry reference
Supply a sketch or drawing identifying the run, branch, connection forms and dimensional units. Add the required material specification, pipe schedules and any project documentation requirements so the technical enquiry describes one complete outlet.
If the project calls for a threadolet, keep the branch thread requirement explicit throughout that review. Confirming the outlet form alongside the run and branch dimensions helps distinguish the requested connection from other forged Olet arrangements.
Informações técnicas para cada consulta
Prepare os requisitos antes da confirmação final do produto.
A página é o ponto de partida. Desenhos, amostras, interfaces, materiais, quantidades e aceitação são avaliados antes de confirmar estoque ou produção.
Discuta este produto no contexto do seu projeto.
Compartilhe desenho, amostra, referência, quantidade e aplicação. Pontos desconhecidos podem ficar em aberto.
