Forged Steel Tee for Instrument Piping

• warranty

  1 Year
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Equal
  head code

  Hexagon
• Overall Length

  Customized Size
  Height

  Customized Size
• Surface Treatment

  Plain
  Pressure

  High Pressure
• System of Measurement

  Metric
  Mounting hole diameter

  Customized Size
• Pipe Features

  Other
  Pipe Class

  Other
• Application

  Other
  Thread Types

  Customized Size

This instrument piping listing describes a forged steel tee with socket weld and ASME B16.11 references. Its original image supports a tee form, while the selectable types are labeled Reducer. Confirm the exact supplied component and drawing before using the title or option label as the order specification.

Define the run, branch and actual ends

Specify both run and branch sizes, center-to-end dimensions, outside diameter and wall requirements. Equal in the table does not establish the selected branch dimensions. The visible tee form cannot supply measurements or verify a particular socket construction, so obtain the actual dimensional drawing.

Clarify the socket weld reference with the required socket and pipe-fit details, welding requirements and inspections. The broad 1/2–110 inch option does not demonstrate availability or standard coverage for every instrument fitting. Confirm the applicable ASME B16.11 edition, scope and actual size or class combination.

Identify the supplied steel and production package

The title names carbon and stainless steel, but the available material labels are Carbon Steel and a234wpb. Request the actual grade, condition and traceability for the proposed component. A material label is not a certificate, and the title does not establish an available stainless configuration.

Agree the manufacturing and inspection records supporting the Forged reference. Customized Size entries and Metric wording do not provide tolerances or drawing dimensions; Hexagon also needs clarification for the selected component. Specify measurable finish criteria beyond Plain and tie all inspections to the approved purchase drawing.

Quantify the instrument piping service

Provide the medium, contamination limits, pressure, temperature, cycles, transients and relevant loads. High Pressure and an Other class entry give no numerical allowable rating. Confirm material, dimensional, end and surface documentation, marking, preservation and delivery. Agree OEM requests and warranty terms separately from the technical acceptance of the selected tee.
