ASME A105 Forged Ball Valve Enquiry for Oil & Gas
Voor industriële inkoop
Bereid een duidelijke RFQ voor
Neem onderstaande gegevens op zodat RELIA het onderdeel begrijpt en de volgende stap kan bespreken.
- Tekening, monster of referentienorm
- Materiaalkwaliteit en voorkeursproces
- Maten, toleranties en oppervlakteafwerking
- Toepassing, doelvolume en bestemming
Productietijd, verpakking en verzendvoorwaarden worden per project bevestigd nadat specificaties en handelsvoorwaarden zijn overeengekomen.
-
applicationGeneralBall MaterialCarbon Steel
-
Connection TypeflangemediaBASE
-
Port Size1/4in - 4instructureControl
-
model numberball valveConnection Size1/4in - 4in
-
customized supportOEM, odmFlow Rate0-100L/min
-
For Maximum Pipe Size4in(10.16cm)Operating Pressure900 psi(62.05bar)
-
Operating Temp. Range0~150 Celsiuspowermanual
-
Sealing MaterialPTFEtemperature of mediaMedium Temperature
-
warranty1 year
An A105 forged ball-valve enquiry for oil or gas service needs a selected mechanism, a precise nominal size and a defined operating rating. Identify the governing project requirements before choosing a valve configuration. A broad size description or a pressure value alone does not establish which assembly meets the pipeline specification. The enquiry should bring those details together for one documented model.
Resolve Nominal Size and Valve Mechanism
Request a section drawing that establishes the operating mechanism of the proposed valve. State the required nominal size and obtain the corresponding port, flange and face-to-face dimensions. Compare those dimensions with the actual mating pipeline drawing. For a large-size requirement, confirm the exact size and model combination rather than assuming that a general range describes every selectable option.
Specify A105 Construction and the ASME Requirement
Identify the exact body material requirement and obtain the associated material documentation. If forged construction is required, have the manufacturing process documented separately. Keep body and ball material specifications distinct. State the applicable ASME standard and edition, the relevant pressure designation and the temperature conditions used for selection. A standard family name needs that specific scope before the proposed assembly can be assessed against it.
Qualify the Actual Oil or Gas Duty
Name the process medium and describe its operating pressure and service temperatures. Include any composition details needed to evaluate seat and seal compatibility. Request the pressure-temperature evidence and sealing specification for the same model shown on the drawings. Complete the enquiry with the selected nominal size, body grade, construction process, standard scope and operating records. Review the full set together so that an isolated table value or photograph marking is not used as the basis for an application decision.
Technische informatie voor elke productaanvraag
Bereid de eis voor vóór de definitieve productbevestiging.
De productpagina is het startpunt. Tekeningen, monsters, interfaces, materialen, aantallen en acceptatie-eisen worden beoordeeld vóór voorraadmatch of maatwerkproductie.
Bespreek dit product binnen uw project.
Deel tekening, monster, referentie, doelaantal en toepassing. Onbekende punten kunnen openblijven voor beoordeling.
