304/316 Full or Half Coupling | Socket-Weld Enquiry
산업 소싱용
명확한 RFQ 준비
RELIA가 부품을 이해하고 다음 단계를 논의할 수 있도록 아래 정보를 포함하세요.
- 도면, 샘플 또는 참고 표준
- 재질 등급 및 선호 공정
- 치수, 공차 및 표면 처리
- 용도, 목표 수량 및 목적지
생산 일정, 포장 및 운송 조건은 사양과 거래 조건 합의 후 프로젝트별로 확정됩니다.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentPaintingMounting hole diameter0.25 in
-
Pipe Class125SizeCustomized Size
-
Product nameElbow
This pipe coupling enquiry needs the actual form and end connection to be identified before the title's full-coupling, half-coupling and 304/316 references can define an offered item. The title and available variants support coupling identity despite an Elbow label in the original table. The internally threaded sleeve photographs also require the connection to be checked against the socket-weld and butt-welding wording.
Choose one coupling form and end specification
Confirm whether the request is for a full or half coupling and obtain a section drawing with overall length, bore and both end details. Do not assign one connection to every option. For a socket-weld requirement, define the socket dimensions and pipe fit. For butt-welding, give bevel and end-wall requirements. If a threaded model is offered, request its exact thread standard, nominal size and engagement; visible threads do not establish the standard or the selected configuration.
Connect 304 or 316 to the selected item
Choose the required stainless-steel grade and its governing material specification, with records linked to the offered coupling. Alloy and carbon-steel alternatives need separate grade identification. Ask how the seamless and Forged references apply to the actual model and request production and inspection evidence before accepting the route. Neither the photographed finish nor generic material options establish a universal 304 or 316 specification.
Complete the dimensional and duty review
Explain the millimetre option's relationship to nominal pipe size and confirm equal-end dimensions, wall and the agreed inspection criteria. Customized Size requires feasibility and drawing confirmation. State the fluid, operating pressure and temperature, corrosion conditions and joining requirements so the entire pipe connection can be assessed. Pipe Class 125, Painting, Hexagon and mounting-hole labels do not qualify pressure-temperature duty, protective finish or measured coupling geometry. Acceptance needs one coordinated form/end drawing, exact material specification and traceable production records.
모든 제품 문의에 필요한 기술 정보
최종 제품 확정 전에 요구사항을 준비하세요.
제품 페이지는 출발점입니다. 재고 매칭 또는 맞춤 생산 확정 전에 도면, 샘플, 인터페이스, 소재, 수량, 검수 요구사항을 검토합니다.
프로젝트 상황에 맞춰 이 제품을 상담하세요.
도면, 샘플, 참조품, 목표 수량, 용도 정보를 공유하세요. 미확정 항목은 검토 상태로 둘 수 있습니다.
