SCH80 Carbon Steel 45-Degree Long-Radius Elbow

• warranty

  3 Years
  customized support

  OEM
• Technic

  FORGED
  Connectivity

  Welding
• shape

  Bend
  head code

  Hexagon
• Overall Length

  1/2" - 12"
  Height

  1/2" - 12"
• Surface Treatment

  smooth
  Pressure

  Low Pressure
• System of Measurement

  INCH
  Mounting hole diameter

  1/2" - 12"
• Pipe Features

  corrosion resistant
  Pipe Class

  Not Rated
• Application

  Construction Engineering
  Thread Types

  NPT

This carbon steel elbow is listed with SCH80, a 45-degree bend and long-radius wording for gas enquiries. The title names a 6-inch selection, while the available option covers 1/2 inch to 12 inch. Confirm the exact ordered size and geometry before treating the listing as a complete specification.

Allocate the bend dimensions to the selected size

Obtain a drawing showing nominal ends, bend angle, radius, wall thickness, overall dimensions and tolerances. Verify the 6-inch title reference against the selected supply. SCH80 needs its governing dimensional document and size allocation; no numerical wall thickness can be established from the label alone.

The table repeats the broad size range under length, height and mounting hole. Assign those fields to actual dimensions or clarify their role. The range does not guarantee every size, and long-radius wording does not replace the required drawing or installation clearance check.

Specify the forged material and actual connections

State the full carbon steel designation, condition, traceability and manufacturing requirements. Confirm the applicable numbered ASME document and edition, with forging, dimensional and inspection records. The general ASME reference does not establish a particular standard or certification.

Resolve Welding and NPT into an actual end schedule. Define welding preparation, any thread designation, mating parts, sealing requirements and examination. These connection labels should not be treated as interchangeable. Agree measurable smooth finish criteria and delivery protection for the selected component.

Qualify gas duty and corrosion expectations

Provide gas composition, operating pressure and temperature, cycling, exposure and mechanical loads. The pressure and class entries give no quantified duty for this selected gas elbow. Request evidence for corrosion performance under those conditions and agree material/joint acceptance, with the selected drawing, connection, production, finish and test records included in the quotation.
