Forged Carbon / Stainless Steel Welding Flange Enquiry
산업 소싱용
명확한 RFQ 준비
RELIA가 부품을 이해하고 다음 단계를 논의할 수 있도록 아래 정보를 포함하세요.
- 도면, 샘플 또는 참고 표준
- 재질 등급 및 선호 공정
- 치수, 공차 및 표면 처리
- 용도, 목표 수량 및 목적지
생산 일정, 포장 및 운송 조건은 사양과 거래 조건 합의 후 프로젝트별로 확정됩니다.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
Surface TreatmentSmoothMounting hole diameter0.17 in
-
Pipe Class150SizeCustomized Size
-
Product nameElbow
This forged carbon/stainless welding-flange enquiry needs confirmation of the actual configuration. The title mentions butt-welding, but actual variants say Flange and reviewed images show closed-centre examples. Obtain the selected section and matching product evidence before specifying a pipe connection or assuming the offered flange closes the line.
Resolve closed or bored geometry before joining instructions
Ask whether the selected flange has a solid centre or a bore and pipe interface. Do not relabel it as blind or weld-neck solely from the photographs. For a documented bored welding configuration, define hub, bore and actual pipe connection with its preparation. For a closed configuration, confirm closure thickness and the mating bolted assembly instead. The imported Elbow name does not establish the supported flange's subtype or installation.
Choose the material and map the actual flange dimensions
Select Carbon Steel, Stainless Steel or Alloy and specify an exact grade with a complete material document and traceable records. Explain each millimetre menu value and its nominal-size convention. Record flange thickness, outside diameter, bolt circle, hole count/diameter and applicable bore/hub or closure dimensions. Generic Equal, Hexagon and mounting-hole fields do not replace that drawing. Customized Size does not prove an offered dimension or supplied range.
Qualify the mating assembly and selected rating basis
Agree one numbered dimensional standard and edition, sealing face and finish with the mating flange, gasket and bolting. Support Forged and Smooth through production and surface inspection evidence. Clarify the standard and unit basis of Pipe Class 150 for the actual size, material and temperature. Provide fluid, pressure, temperature, corrosion and mechanical loads for full joint assessment. Include welding and inspection requirements only where the selected installation actually uses a weld connection.
모든 제품 문의에 필요한 기술 정보
최종 제품 확정 전에 요구사항을 준비하세요.
제품 페이지는 출발점입니다. 재고 매칭 또는 맞춤 생산 확정 전에 도면, 샘플, 인터페이스, 소재, 수량, 검수 요구사항을 검토합니다.
프로젝트 상황에 맞춰 이 제품을 상담하세요.
도면, 샘플, 참조품, 목표 수량, 용도 정보를 공유하세요. 미확정 항목은 검토 상태로 둘 수 있습니다.
