Carbon and Stainless Steel Pipe Fitting Reducer
산업 소싱용
명확한 RFQ 준비
RELIA가 부품을 이해하고 다음 단계를 논의할 수 있도록 아래 정보를 포함하세요.
- 도면, 샘플 또는 참고 표준
- 재질 등급 및 선호 공정
- 치수, 공차 및 표면 처리
- 용도, 목표 수량 및 목적지
생산 일정, 포장 및 운송 조건은 사양과 거래 조건 합의 후 프로젝트별로 확정됩니다.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
TechnicForgedConnectivityWelding
-
shapeEqualhead codeHexagon
-
SizeCustomized SizeProduct nameElbow
A pipe fitting reducer is selected to connect a larger pipe end with a smaller one. This product offers Stainless Steel, Alloy and Carbon Steel material choices; the required reducer geometry and both end dimensions should be defined together before selecting a configuration.
Draw the size transition and its orientation
For an eccentric reducer request, show the required offset and orientation on a dimensioned drawing. Confirm whether the transition must be eccentric or concentric, because the size change alone does not define the relationship between the two pipe centerlines.
The drawing should locate the large and small ends within the intended pipe arrangement. That gives the geometry review a clear reference without relying on a photograph to establish dimensions or the exact supplied form.
Specify two ends rather than one size label
Provide the large-end and small-end sizes with their units and dimensional designations. Add the wall thickness and required welding end preparation at each end so the transition can be checked against both adjoining pipes.
Choose the material family separately and state the required grade. A Stainless Steel selection does not by itself establish 316 material, just as an end-size selection does not identify the entire reducer configuration.
Confirm construction for the requested reducer
If the project requires seamless construction or a particular forming method, include that requirement in the enquiry and obtain confirmation for the selected part. Appearance alone cannot verify manufacturing method, material grade or service capability.
Supply the applicable standard, medium and design conditions along with the drawing before judging pressure and temperature suitability. For an eccentric transition, the decisive enquiry details remain the two-end dimensions and drawing-defined offset, with the material and construction requirements tied to that same reducer.
모든 제품 문의에 필요한 기술 정보
최종 제품 확정 전에 요구사항을 준비하세요.
제품 페이지는 출발점입니다. 재고 매칭 또는 맞춤 생산 확정 전에 도면, 샘플, 인터페이스, 소재, 수량, 검수 요구사항을 검토합니다.
프로젝트 상황에 맞춰 이 제품을 상담하세요.
도면, 샘플, 참조품, 목표 수량, 용도 정보를 공유하세요. 미확정 항목은 검토 상태로 둘 수 있습니다.
