Carbon Steel Eccentric Butt-Weld Reducer | Geometry and End Enquiry
산업 소싱용
명확한 RFQ 준비
RELIA가 부품을 이해하고 다음 단계를 논의할 수 있도록 아래 정보를 포함하세요.
- 도면, 샘플 또는 참고 표준
- 재질 등급 및 선호 공정
- 치수, 공차 및 표면 처리
- 용도, 목표 수량 및 목적지
생산 일정, 포장 및 운송 조건은 사양과 거래 조건 합의 후 프로젝트별로 확정됩니다.
-
warranty1 yearcustomized supportOEM, ODM, OBM
-
model number2306TechnicForged
-
ConnectivityWeldingshapeEqual
-
head codeHexagonOverall Length4 in
-
Height3Surface TreatmentPainting
-
PressureLow PressureSystem of Measurementinch
-
Mounting hole diameter0.25 inPipe FeaturesFlexible, Corrosion-resistant, Chemical Resistant, Uv Resistant, No additional Features, underground rated
-
Pipe ClassNot RatedApplicationAgricultural Irrigation, Automotive Repair, Heating Systems, Power Industry, Construction Engineering, Shipbuilding, petrochemical industry
-
Thread TypesGSizeCustomized Size
This carbon-steel enquiry requests an eccentric butt-weld reducer, but the table includes Equal geometry and a G-thread entry. Reducer variants and the tapered-fitting photograph support the family. Reconcile the selected geometry and actual end construction before accepting pipe fit, joining requirements or any listed performance feature.
Resolve offset geometry and the dimension units
Obtain larger and smaller end nominal sizes, outside diameters, actual walls, overall length, centreline offset and transition profile. Define eccentric orientation on the intended line drawing. Explain which end the millimetre option denotes and identify the other end. Reconcile the inch entry, four-inch overall length and unitless height against selected dimensions. Equal, Hexagon and mounting-hole fields do not establish that drawing, and the photograph cannot qualify exact offset or dimensions for every variant.
Confirm actual ends and traceable material
Resolve G-thread wording against Butt-Welding and Welding before deciding connection construction. Confirmed butt-weld ends need agreed preparation, alignment, joining procedure and inspection access. A threaded alternative requires its own complete connection and sealing specification. Select Carbon Steel with an exact specification, grade and traceable records; Stainless Steel and Alloy alternatives need separate assignments. Agree applicable dimensional requirements and verify Forged and Painting through production, inspection and coating or weld-zone evidence.
Assess the reducer in its actual operating environment
The flexibility, resistance and underground claims lack selected evidence, while No additional Features prevents accepting the feature list collectively. Listed industries do not establish application approval. Low Pressure and Not Rated do not define allowable duty. Provide actual fluid, pressure, temperature, corrosion, environment and mechanical loads for complete-transition assessment under applicable requirements. Confirm feasible dimensions and availability beyond Customized Size, then base acceptance on reconciled geometry/ends and selected material, production, joining and service records.
모든 제품 문의에 필요한 기술 정보
최종 제품 확정 전에 요구사항을 준비하세요.
제품 페이지는 출발점입니다. 재고 매칭 또는 맞춤 생산 확정 전에 도면, 샘플, 인터페이스, 소재, 수량, 검수 요구사항을 검토합니다.
프로젝트 상황에 맞춰 이 제품을 상담하세요.
도면, 샘플, 참조품, 목표 수량, 용도 정보를 공유하세요. 미확정 항목은 검토 상태로 둘 수 있습니다.
